Appendix
Eagles Nest Residences Site Plan
April 5, 2022Page 1201 section
An architectural site plan for the Eagles Nest Residences showing proposed building footprints ranging from 3 to 6 storeys and preserved landscape areas.
Project Name: Eagles Nest ResidencesAddress: Helmcken RdArchitect: dHKarchitectsDrawing No. A101
Eagles Nest Residences
Helmcken Rd, View Royal BC
Site Plan
| Rev | Date | Description |
|---|---|---|
| - | 17 SEP 2018 | ISSUED FOR REZONING |
| 1 | 28 JUN 2019 | RE-ISSUED FOR REZONING |
| 1 | 22 JAN 2020 | RE-ISSUED FOR REZONING |
Project Metadata
- Project Number: 1827
- Date: 22 JAN 2020
- Drawing No: A101
- Scale: 1:250
- Drawn by: EDS
- Checked by: RAW
- Note: All dimensions are shown in millimeters.
Architect Information
- Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367
- Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 0H2 | T 1 • 250 • 585 • 5810
Site Features and Building Heights The site plan illustrates a residential development situated at the corner of Helmcken Road and Burnside Road. Key features and building specifications include:
- Building Storeys:
- 6 Storeys (North building)
- 5 Storeys (Multiple locations)
- 4 Storeys (Multiple locations)
- 4 Storeys (With partial 5th floor)
- 3 Storeys (Multiple locations)
- Landscaping and Public Realm:
- Community Green (Central courtyard area)
- Woonerf
- Feature Rain Garden
- Preserved Trees and Landscape areas
- Preserved Rock Outcrop
- Property Boundaries:
- Property Lines clearly demarcated along all sides.
- Primary access/frontage on Helmcken Road and Burnside Road.
Legal Notice COPYRIGHT RESERVED. THESE PLANS AND DESIGNS ARE AND AT ALL TIMES REMAIN THE PROPERTY OF DHKARCHITECTS TO BE USED FOR THE PROJECT SHOWN AND MAY NOT BE REPRODUCED WITHOUT WRITTEN CONSENT.
Page 120
