Council Meeting/Documents/Drawing 1: Glentana Village Site Plan

Appendix

Drawing 1: Glentana Village Site Plan

May 17, 2022Page 2391 section

Architectural site layout showing the position of all housing clusters and the recreation center.

10.a Zoning Bylaw No. 900, 2014, Amendment Bylaw No. 1101, 2022 to Rezone the Glentana Village Land Use Contract Area

Donald Macpherson, ArchitectGlentana RoadRecreation Centre

GLENTANA VILLAGE : ADKE CONST. LTD

VICTORIA B.C.

SCHEDULE C

Text fragments from the site plan including the project title and legend

SITE PLAN

Architect: DONALD MACPHERSON — ARCHITECT
Address: 582 GOLDSTREAM AVE VIC. 474-1531
Scale: 1" = 40' 0"
Date: SEPT 1977
Drawn by: A. VAGLIONO
Drawing No: -112

Detail of site plan showing residential clusters and a north arrow

Detail of site plan showing Glentana Road and central housing layout

Detail of site plan showing the lower section of residential unit clusters

Detail showing the architectural title block and individual unit markings on the site plan

LEGEND

R RECREATION CENTRE
P PATIO HOMES - UNITS A, B, C, D, E, OR F (200% PARKING)
D DUPLEXED UNITS (200% PARKING)
M MAISONETTES (150% PARKING)
T TOWNHOUSES (150% PARKING)

Detail of the legend listed on the site plan

Site Features

GLENTANA ROAD (Main access road)
RECREATION area (marked with 'H')
Designated PARKING areas throughout the development

Detail showing the "RECREATION" label located on the site plan

Page 239
