Drawing 5: Patio Home Relationship Plan

GLENTANA VILLAGE: ASKE CONST.

SET BACK FROM PRIVATE ROAD TO ALLOW FOR PARKING TWO CARS EACH UNIT
COVERED PARKING SHALL BE PROVIDED FOR
SET BACK FROM DEDICATED ROADS TO BE 10' 0" MINIMUM
PATIO HOMES SHALL BE LOCATED WITH ONE WALL ON A PROPERTY LINE TO PROVIDE MAXIMUM USABLE SPACE BETWEEN UNITS (15'-0" MIN. SIDEYARD)
UNITS SHALL BE LOCATED TO TAKE ADVANTAGE OF THE SITE CONTOURS & ORIENTATION
WINDOWS AND DOORS IN ADJACENT UNITS SHALL BE POSITIONED TO CREATE PRIVACY AND INDIVIDUALITY BETWEEN UNITS
OUTDOOR LIVING AREAS (ENTRANCES) SHALL BE PRIVATE OR SCREENED FROM ADJACENT UNITS
EXISTING TREES SHALL BE RETAINED WHERE POSSIBLE AS SPECIFIED IN THE CONTRACT
LANDSCAPING OR RETENTION OF NATURAL VEGETATION IS REQUIRED FOR ALL AREAS
