Appendix
PROPOSED SITE PLAN - Canadian Tire Corp. (A-101)
November 15, 2022Page 712 sections
Architectural site plan showing the proposed building footprint, parking layout, and landscaping for 1519 Admirals Rd.
October 18, 2022Total site parking: 205 stallsProject No. 22021
SITE PLAN
Project: Canadian Tire Corp., 368 View Royal, BC Address: 1519 Admirals Rd., Victoria, BC V9A 2P8 Architect: MGBA Architecture + Interior Design Drawing No: A-101 Project No: 22021 Date: OCTOBER 18, 2022
REVISION TABLE
| REV | MM/DD/YY | DESCRIPTION | DR | RV |
|---|---|---|---|---|
| 1 | 02/18/2022 | ISSUED FOR CLIENT REVIEW | AM | RH |
| 2 | 02/25/2022 | ISSUED FOR STORE PLANNING | RH | RH |
| 3 | 03/14/2022 | ISSUED FOR CLIENT REVIEW | RH | AB |
| 4 | 03/22/2022 | ISSUED FOR CLIENT REVIEW | JT | RH |
| 5 | 04/27/2022 | ISSUED FOR COORDINATION | RH | RH |
| 6 | 05/16/2022 | ISSUED FOR REVIEW | RH | RH |
| 7 | 10/18/2022 | RE-ISSUED FOR DP | RH | RH |
SITE INFORMATION
- CIVIL ADDRESS: 1519 ADMIRALS RD. VICTORIA, BC V9A 2P8
- LEGAL ADDRESS: LOT 1, SECTION 2, ESQUIMALT DISTRICT, PLAN VIP72795, EXCEPT PLAN EPP63581
ZONING ANALYSIS
- ZONING GROUP: C-1 COMMUNITY COMMERCIAL
- SITE AREA: 223,348 sf (5.13 Acres)
LOT DENSITY
- FLOOR SPACE RATIO, BASE DENSITY: 0.6
- LOT COVERAGE, MAXIMUM: 50%
- PROPOSED LOT COVERAGE: 27.8%
- IMPERMEABLE SURFACE COVERAGE, MAXIMUM: 80.0%
- PROPOSED IMPERMEABLE SURFACE COVERAGE: 79.8%
BUILDING SIZE
- BUILDING HEIGHT, MAXIMUM: 9m
- PR. BUILDING HEIGHT: 28.6 feet (8.7m max)
- BUILDING WIDTH, MINIMUM: 6m
- ACCESSORY BUILDING HEIGHT, MAXIMUM: 4.5m
SITING
- FRONT LOT LINE SETBACK: 24.5 feet (7.5m)
- REAR LOT LINE SETBACK: 24.5 feet (7.5m)
- SIDE LOT LINE SETBACK: 19.7 feet (6.0m)
- FLANKING LOT LINE SETBACK: 9.8 feet (3.0m)
ADDITIONAL SITE METRICS
- EX. SITE FLOOR AREA: 66,562 sf (6,184 m2)
- EX. CT FLOOR AREA: 60,032 sf (5,577 m2)
- EX. SITE COVERAGE: 29.8%
- PR. SITE FLOOR AREA: 89,076 sf (8,276 m2)
- PR. CT FLOOR AREA: 82,546 sf (7,669 m2)
- PR. SITE COVERAGE: 39.9%
VEHICLE PARKING
- PARKING REQUIRED: 283.0 stalls
- RETAIL STORE - 3,438m² (1/20m²): 171.9 stalls
- FROST HOUSE - 223m² (1/20m²): 11.2 stalls
- SERVICE CENTRE (2 + 2/BAY): 26.0 stalls
- WAREHOUSE - 3,219m² (1/175m²): 18.4 stalls
- OFFICE - 381m² (1/30m²): 12.7 stalls
- CRU 1 - RETAIL - 374m² (1/20m²): 18.7 stalls
- CRU 1 - RESTAURANT - 233m² (1/10m²): 23.3 stalls
- PARKING PROVIDED: 205.0 stalls
- ACCESSIBLE: 4 stalls
BICYCLE PARKING
- SPACES REQUIRED:
- SHOPPING CENTRE:
- 5,000m² (1/250m²): 20.0 spaces
- 56m² (1/500m²): 0.1 spaces
- WAREHOUSE 3,219m²: 3.4 spaces
- SHOPPING CENTRE:
- BICYCLE PARKING REQUIRED*: 9 CLASS 1, 16 CLASS 2
- BICYCLE PARKING PROVIDED: 10 CLASS 1, 20 CLASS 2 * CLASS 1 BICYCLES LOCATED WITHIN ENCLOSED SPACE WITH POWER
STATISTICS TABLE
| # | STATISTICS | % | EXISTING (IMPERIAL / METRIC) | PROPOSED EXPANSION (IMPERIAL / METRIC) |
|---|---|---|---|---|
| 1 | RETAIL | 52% | 28,559 / 2,653 | +/-37,008 / 3,438 |
| 2 | WAREHOUSE | |||
| 3 | GROUND FLOOR | 7,829 / 727 | +/-11,567 / 1,075 | |
| 4 | MEZZANINE | 2,450 / 228 | +/-12,777 / 1,187 | |
| 3b | BASEMENT | 10,307 / 958 | +/-10,307 / 958 | |
| 4 | TOTAL | 48% | 20,586 / 1,913 | +/-34,651 / 3,219 |
| 5 | SERVICE CENTRE (12 BAYS) | |||
| 6 | GROUND FLOOR | 6,553 / 609 | 6,553 / 609 | |
| 7 | MEZZANINE | 230 / 21 | 230 / 21 | |
| 10 | TOTAL | 6,783 / 630 (10) | 6,783 / 630 (10) | |
| 8 | OFFICES | |||
| 9 | GROUND FLOOR | 369 / 34 | 369 / 34 | |
| 10 | MEZZANINE | 3,735 / 347 | 3,735 / 347 | |
| 11 | TOTAL | 4,104 / 381 | 4,104 / 381 | |
| 13 | BUILDING STRUCTURAL AREA (13+3b+6+9) | 57,582 / 5,350 | +/-69,769 / 6,482 | |
| 14 | BUILDING FUNCTIONAL AREA (14+3) | 60,032 / 5,577 | +/-82,546 / 7,669 | |
| 15 | GARDEN CENTRE | |||
| 16 | CANOPY | 3,737 / 347 | - | |
| 17 | COMPOUND | 6,037 / 561 | +/-8,548 / 794 | |
| 18 | TOTAL | 9,774 / 908 | +/-8,548 / 794.1 | |
| 19 | CRU 1 BUILDING AREA | 6,530 / 607 | 6,530 / 607 | |
| 21 | TOTAL GROUND FLOOR COVERAGE (13+19+20) | 49,840 / 4,630 | +/-62,027 / 5,762 | |
| 25 | SITE AREA | 5.13 ac. / 223,348 / 20,750 | 5.13 ac. / 223,348 / 20,750 | |
| 26 | CTC STORE SITE PARKING | 181 | 179 | |
| 27 | CRU 1 SITE PARKING | 27 | 27 | |
| 29 | OVERALL SITE PARKING (26+27+28) | 208 | 205 | |
| 30 | PARKING RATIO (/1000 SF) | 4.17 | 3.31 | |
| 31 | PARKING RATIO (/100 SM) | 4.49 | 3.56 |
(1) PROPOSED SITE PLAN
Scale: 1/32" = 1'-0"
Page 71
The plan shows the proposed expansion of the Canadian Tire store (#368) and surrounding site features:
- Proposed Canadian Tire Retail and Automotive Centre Store #368: Total Retail (37,008 sf), Total Warehouse (34,651 sf), Total Service Centre (6,783 sf).
Detail of proposed CTC retail interior area
Detail of proposed warehouse interior area
Detail of proposed Service Centre area layout
Detail of proposed warehouse area layout
Detail of proposed retail area layout
Detail of proposed office area layout
Detail of interior layout lines
Detail of proposed building footprint
Detail of interior retail shelving lines
Detail of proposed Service Centre mezzanine
Detail of proposed warehouse interior
Detail of proposed warehouse ground floor
Detail of proposed retail ground floor
Detail of proposed CTC store area
Detail of proposed store shelving layout
- Garden Centre: 8,548 sf.
Detail of proposed Garden Centre area
Detail of Garden Centre compound
- Existing CRU 1 Building: Including Retail and Restaurant areas.
Detail of CRU 1 building corner
Detail of CRU 1 building entrance
Detail of CRU 1 roof area
- Parking Information:
- CTC Store Site Parking: 178 Stalls
- Total Site Parking: 205 Stalls
Detail of parking area near CRU 1
Detail of parking aisle and stalls
Detail of CTC store entrance and parking stalls
Detail of accessible parking stall
Detail of parking stalls and landscaping island
Detail of landscaping planter
Detail of parking stall and curb
Detail of parking aisle along Old Island Highway
Detail of parking rows on north side
Detail of parking stalls and aisle
Detail of parking aisle layout
- Site Features and Boundary detail:
- Admirals Road, Glentana Road, Old Island Highway.
- Existing Loading Ramp and Transformer.
- New Pedestrian Connection and EV Charging Stations.
- Bicycle Parking: Class 1 Long-term Bicycle Stations and Class 2 Short-term Bicycle Racks.
- Designated E-Comm Parking Spaces.
- Existing Retaining Walls.
Detail of loading ramp area
Detail of Admirals Road property line
Detail of landscaping and walkway
Detail of north retaining wall
Detail of landscaping strip
Detail of Admirals Road pavement
Detail of northern boundary landscaping
Detail of north property line and retaining wall
Detail of road edge and curb
Detail of north-west property line
Detail of Admirals Road markings
Detail of north boundary corner
Detail of store building walls
Detail of northern property line
Detail of northern retaining wall section
Detail of Glentana Road boundary
Detail of north-west corner retaining wall
(3) EXISTING SITE PLAN
Scale: 1" = 50'-0"
The plan shows the current configuration of the site:
- Existing Canadian Tire Retail and Automotive Centre Store #368: Includes Warehouse, Outdoor Garden Centre, Service Centre, and Office.
Detail of existing CTC store area
Detail of existing warehouse area
Detail of existing CTC store building
Detail of existing warehouse area
Detail of existing Service Centre area
- Existing CRU 1:
Detail of existing CRU 1 building
- Existing Parking Information:
- CTC Store Site Parking: 181 Stalls
- Total Site Parking: 208 Stalls
Detail of existing parking layout
Detail of existing parking stall row
- Other Existing Features:
- Existing trees to be removed (8).
- Existing loading area and Service Centre bays.
Detail of existing loading area
Detail of existing site plan corner at Glentana Road
Detail of existing site plan edge
Detail of Admirals Road edge on existing plan
Detail of south property line on existing plan
Detail of north-east property corner
Detail of existing plan northern boundary
Detail of existing Glentana Road edge
Detail of existing northern property line
Detail of existing Admirals Road edge
Page 71
