Appendix
West Park One - Project Information (A002)
July 19, 2022Page 521 section
Technical calculation sheet determining the average grade of the building site for height measurement purposes.
Average Grade: 67.4Building perimeter: 158.7m
West Park One
Project Information
Victoria, BC 03 JUN 2022
[Map: Site plan showing existing contours, proposed property lines, and the perimeter of the building where it meets grade. Points A through V are marked along the building perimeter.]
- EXISTING CONTOURS.
- PERIMETER OF BUILDING WHERE IT MEETS GRADE.
Grade Calculation
| POINTS | AVERAGE | DISTANCE | TOTAL |
|---|---|---|---|
| A&B | ((69.5 + 67.7)/2) | 16.6 | 1138.76 |
| B&C | ((67.7 + 63.8)/2) | 30 | 1972.5 |
| C&D | ((63.8 + 64.3)/2) | 30 | 1921.5 |
| D&E | ((64.3 + 69.5)/2) | 16.6 | 1110.54 |
| E&F | ((69.5 + 69.5)/2) | 3.2 | 222.4 |
| F&G | ((69.5 + 69.5)/2) | 3.2 | 222.4 |
| G&H | ((69.5 + 69.5)/2) | 7 | 486.5 |
| H&I | ((69.5 + 69.5)/2) | 1.5 | 104.5 |
| I&J | ((69.5 + 69.5)/2) | 4.7 | 326.65 |
| J&K | ((69.5 + 69.5)/2) | 1.5 | 104.25 |
| K&L | ((69.5 + 69.5)/2) | 3.6 | 250.2 |
| L&M | ((69.5 + 69.5)/2) | 3.0 | 208.5 |
| M&N | ((69.5 + 69.5)/2) | 3.5 | 243.25 |
| N&O | ((69.5 + 69.5)/2) | 4.5 | 312.75 |
| O&P | ((69.5 + 69.5)/2) | 1.5 | 104.25 |
| P&Q | ((69.5 + 69.5)/2) | 7.2 | 500.4 |
| Q&R | ((69.5 + 69.5)/2) | 1.5 | 104.25 |
| R&S | ((69.5 + 69.5)/2) | 4.7 | 326.65 |
| S&T | ((69.5 + 69.5)/2) | 1.5 | 104.25 |
| T&U | ((69.5 + 69.5)/2) | 7 | 486.5 |
| U&V | ((69.5 + 69.5)/2) | 3.2 | 222.4 |
| V&A | ((69.5 + 69.5)/2) | 3.2 | 222.4 |
| TOTAL | 158.7 | 10,695.8 |
AVERAGE GRADE: 10,695.8 / 158.7 = 67.4
Average Grade Scale: 1:200
