Appendix
West Park One - Architectural Site Plan (A101)
July 19, 2022Page 531 section
Site plan showing the footprint of the proposed building, including property line setbacks, ramp access to the parkade, and landscaping locations.
Front setback: 5.503 mRear setback: 5.457 mSide setback (south): 4.152 m2000 West Park Lane
West Park One
Project: West Park One Properties Ltd.
Location: Victoria, BC
Date: 03 JUN 2022
Architectural Site Plan
Sheet Number: A101
Scale: 1:200
Site Features and Annotations
- Access and Infrastructure:
- Ramp down to parkade
- Line of parkade below
- Sidewalk
- Road (access on west and south sides)
- Bicycle parking (six spots)
- Electrical transformer
- Setbacks:
- 5513 mm
- 6796 mm
- 5457 mm
- 4152 mm
- Landscape and Grading:
- Planter walls (Refer to landscape drawings)
- Landscaping (Refer to landscape drawings)
- Retaining walls (Refer to landscape drawings)
- Existing contours (Values labeled from 54 to 69)
- 69.500 Contour - L1 Main Floor Level
- 63.500 Contour - Approximate Level of P2
- Property Boundaries:
- Property lines and proposed property lines indicated
- Adjacent Context:
- 2-storey townhouse typical (adjacent property)
- Playground area
Building Layout and Internal Notations
The site plan illustrates a multi-unit building footprint with typical interior appliance and utility notations:
- W/D: Washer/Dryer
- S: Sink
- F: Fridge
- DW: Dishwasher
Page 53
