West Park One - Plan P1 Upper Level (A102)

July 19, 2022Page 541 section

Floor plan for the upper parkade level showing parking stall layouts and a dedicated bicycle storage room.

1 CALL TO ORDER
26 parking stalls48 bicycle spacesGarbage and recycling rooms included

Plan P1 Upper Level - West Park One

Location: Victoria, BC Date: 03 JUN 2022 Architect: dHKarchitects Sheet: A102 Scale: 1:100

Site Details

  • Parking: 26 stalls total
  • Bicycle Room: 48 spaces
  • Facilities:
    • Electrical
    • Mech.
    • Garbage Room
    • Transformer Above
    • Elec.
  • Access:
    • Ramp Up
    • Ramp Up From Below

Plan Annotations

  • Retaining walls, see landscape.
  • Line of building above.
  • Line of parkade below.
  • Elevations: 66.460, 69.450, 67.050, 66.525.
  • Stall numbering: 1-26.

Dimensions (mm)

  • North Boundary: 29993
  • East Boundary Segments: 13993, 16000
  • South Boundary Arc Segments: 9200, 6800, 6000, 6000, 6800, 9200
  • West Boundary Segments: 6300, 5800, 6700, 5800
  • Vertical Span (East Side): 24600
  • Typical Stall/Area Widths: 2100, 2600, 2900, 3000, 3100, 3200, 3300, 6300
Page 54
