West Park One - Plan P2 Lower Parking Level (A103)

July 19, 2022Page 551 section

Floor plan for the lower parkade level including additional parking stalls and resident storage lockers.

1 CALL TO ORDER
34 parking stalls48 storage lockers

West Park One

Plan P2 Lower Parking Level

Project Information

  • Client: West Park One Properties Ltd., Victoria, BC
  • Date: 03 JUN 2022
  • Sheet Number: A103
  • Scale: 1:100
Architectural floor plan for Plan P2 Lower Parking Level showing 34 parking stalls, 48 storage lockers, elevator, and ramp access.
Architectural floor plan for Plan P2 Lower Parking Level showing 34 parking stalls, 48 storage lockers, elevator, and ramp access.

Drawing Components

  • Parking: 34 stalls (numbered 1 through 34)
  • Storage: 48 lockers
  • Circulation and Services:
    • Elevator (ELEV.)
    • Ramp Up (noted in two locations)
    • Line of parkade above
  • Site Features:
    • Retaining wall (refer to landscape drawings)
  • Elevations:
    • 63.580
    • 63.845

Key Dimensions (mm)

  • Grid and External Dimensions: 6100, 9200, 6800, 13993, 28100, 4800, 9100, 1600.
  • Internal and Bay Dimensions: 6300, 2900, 10200, 14500, 6000.
