West Park One - Plan L1 Main Floor (A201)
July 19, 2022Page 562 sections
Detailed floor plan for the main residential level, labeling suite numbers 101 through 112 and their respective types.
Suites 101-112Includes lobby and vestibule
West Park One Properties Ltd.
Victoria, BC 03 JUN 2022
Page 56
West Park One
Plan L1 - Main Floor
Drawing Information:
- Drawing Number: A201
- Scale: 1:100
Floor Plan Suite Designations:
- Suite 101: TYPE C
- Suite 102: TYPE C
- Suite 103: TYPE B
- Suite 104: TYPE A
- Suite 105: TYPE C
- Suite 106: TYPE C
- Suite 107: TYPE D
- Suite 108: TYPE C
- Suite 109: TYPE C
- Suite 110: TYPE A
- Suite 111: TYPE B
- Suite 112: TYPE C-1
- VESTIBULE
Notes:
- LINE OF PARKADE BELOW
UNPROTECTED OPENING LIMITS PER TABLE 3.2.3.1 D
| SUITE # | DIRECTION | AREA OF EXPOSING BUILDING FACE (SM) | AREA OF UNPROTECTED OPENINGS (SM) | LIMITING DISTANCE (M) | AREA OF UNPROTECTED OPENINGS (%) ALLOWABLE | AREA OF UNPROTECTED OPENINGS (%) ACTUAL |
|---|---|---|---|---|---|---|
| 101, 102 | WEST | 18.4 | 7 | 10 | 100 | 38 |
| 103 | WEST | 25 | 7 | 10 | 100 | 28 |
| 103 | NORTH | 26.7 | 7 | 6 | 100 | 26 |
| 104 | NORTH | 26.7 | 7 | 6 | 100 | 26 |
| 104 | EAST | 25 | 8 | 6 | 100 | 32 |
| 105, 106, 108, 109 | EAST | 18.4 | 7 | 6 | 100 | 38 |
| 107 | EAST | 39 | 14 | 10 | 100 | 36 |
| 110 | EAST | 25 | 8 | 6 | 100 | 32 |
| 110 | SOUTH | 26.7 | 7 | 4 | 78 | 26 |
| 111 | SOUTH | 26.7 | 7 | 4 | 78 | 26 |
| 111 | WEST | 25 | 7 | 10 | 100 | 28 |
| 112 | WEST | 18.4 | 7 | 10 | 100 | 38 |
