West Park One - Plan L2 (A202)
July 19, 2022Page 571 section
Detailed floor plan for the second residential level of the development.
Suites 201-212Mix of 1-bed and 2-bed units
West Park One
Plan L2
The Level 2 floor plan shows the following suite layouts:
- TYPE F: Suite 201
- TYPE C: Suite 202
- TYPE E: Suite 203
- TYPE A: Suite 204
- TYPE C: Suite 205
- TYPE C: Suite 206
- TYPE D: Suite 207
- TYPE C: Suite 208
- TYPE C: Suite 209
- TYPE A: Suite 210
- TYPE E: Suite 211
- TYPE C: Suite 212
Unprotected Opening Limits per Table 3.2.3.1 D
| SUITE # | DIRECTION | AREA OF EXPOSING BUILDING FACE (SM) | AREA OF UNPROTECTED OPENINGS (SM) | LIMITING DISTANCE (M) | AREA OF UNPROTECTED OPENINGS (%) - ALLOWABLE | AREA OF UNPROTECTED OPENINGS (%) - ACTUAL |
|---|---|---|---|---|---|---|
| 201 | WEST | 27.5 | 11.3 | 10 | 100 | 41 |
| 202 | WEST | 18.4 | 7 | 10 | 100 | 38 |
| 203 | WEST | 31.6 | 9.1 | 10 | 100 | 29 |
| NORTH | 26.7 | 7 | 6 | 100 | 29 | |
| 204 | NORTH | 26.7 | 7.8 | 6 | 100 | 26 |
| EAST | 25 | 8 | 6 | 100 | 32 | |
| 205, 206, 208, 209 | EAST | 18.4 | 7 | 6 | 100 | 38 |
| 207 | EAST | 39 | 14 | 10 | 100 | 36 |
| 210 | EAST | 25 | 8 | 6 | 100 | 32 |
| SOUTH | 26.7 | 7 | 4 | 78 | 26 | |
| 211 | SOUTH | 26.7 | 7 | 4 | 78 | 26 |
| WEST | 31.6 | 9.1 | 10 | 100 | 29 | |
| 212 | WEST | 18.4 | 7 | 10 | 100 | 38 |
Project Information:
- Project Name: West Park One
- Client: West Park One Properties Ltd.
- Location: Victoria, BC
- Date: 03 JUN 2022
- Drawing Title: Plan L2
- Sheet Number: A202
- Scale: 1:100
