West Park One - Plan L3 & L4 (A203)
July 19, 2022Page 581 section
Detailed floor plan for residential levels three and four of the building.
Suites 301-312 (and similar for L4)
West Park One
Victoria, BC 03 JUN 2022
Plan L3 & L4
[Diagram: Floor plan for levels 3 and 4, identifying suite units 301 through 312. The plan shows suite types including Type A (304, 310), Type C (302, 305, 306, 308, 309, 312), Type D (307), Type E-1 (303, 311), and Type F (301), along with central common areas and stairwells.]
L3 SHOWN, L4 SIMILAR.
Scale 1:100 Drawing No. A203
Unprotected Opening Limits per Table 3.2.3.1 D
| SUITE # | AREA OF EXPOSING BUILDING FACE (SM) | AREA OF UNPROTECTED OPENINGS (SM) | LIMITING DISTANCE (M) | AREA OF UNPROTECTED OPENINGS (%) ALLOWABLE | AREA OF UNPROTECTED OPENINGS (%) ACTUAL |
|---|---|---|---|---|---|
| 301 WEST | 27.5 | 11.3 | 10 | 100 | 41 |
| 302 WEST | 18.4 | 7 | 10 | 100 | 38 |
| 303 WEST | 31.6 | 9.1 | 10 | 100 | 29 |
| 303 NORTH | 26.7 | 7 | 6 | 100 | 29 |
| 304 NORTH | 26.7 | 7.8 | 6 | 100 | 26 |
| 304 EAST | 25 | 8 | 6 | 100 | 32 |
| 305, 306, 308, 309 EAST | 18.4 | 7 | 6 | 100 | 38 |
| 307 EAST | 39 | 14 | 10 | 100 | 36 |
| 310 EAST | 25 | 8 | 6 | 100 | 32 |
| 310 SOUTH | 26.7 | 7 | 4 | 78 | 26 |
| 311 SOUTH | 26.7 | 7 | 4 | 78 | 26 |
| 311 WEST | 31.6 | 9.1 | 10 | 100 | 29 |
| 312 WEST | 18.4 | 7 | 10 | 100 | 38 |
