Appendix
West Park One - Roof Plan (A204)
July 19, 2022Page 591 section
Roof layout plan detailing drainage slopes, overflow drains, and mechanical unit positioning.
2% slope to drainMechanical unit location
West Park One
Project: West Park One Properties Ltd. Location: Victoria, BC Date: 03 JUN 2022
Roof Plan
Sheet Number: A204 Scale: 1:100 Graphic Scale: 0 — 2500 — 5000 mm
Drawing Annotations and Details:
- Drainage:
- RD: ROOF DRAIN (RD)
- ORD: OVERFLOW ROOF DRAIN (ORD)
- 2% SLOPE TO DRAIN TYPICAL (indicated at various locations across the roof surface)
- Roof Elements:
- MECHANICAL UNIT
- ROOF HATCH
- LINE OF WALL BELOW
- Grid Layout:
- Numerical Grid Lines: 1, 2, 3, 4, 5, 6, 7
- Alphabetical Grid Lines: A, B, C, D, E
- Section and Detail Callouts:
- 1/A301, 2/A301
- 1/A302, 2/A302
- 1/A401, 2/A401
- 1/A402, 2/A402, 3/A402
Page 59
