West Park One - Exterior Elevations (A302)
July 19, 2022Page 611 section
Architectural drawings showing the North and South side elevations of the building.
Average grade level: 67.400South elevation includes electrical room access
West Park One
West Park One Properties Ltd. Victoria, BC 03 JUN 2022
Exterior Elevations - A302
North Elevation (2)
- Scale: 1:100
- Features: Ramp, Property Lines
South Elevation (1)
- Scale: 1:100
- Features: Electrical Room, Transformer (shown dashed), Property Lines
Building Heights and Levels
| Level / Height Reference | Elevation / Measurement |
|---|---|
| TOP OF ROOF SHEATHING | 81.830 |
| L4 | 78.830 |
| L3 | 75.770 |
| L2 | 72.710 |
| L1 MAIN FLOOR | 69.650 |
| AVERAGE GRADE | 67.400 |
| P1 | 66.460 |
| P2 | 63.580 |
| BUILDING HEIGHT (BCBC) | 16130 |
| BUILDING HEIGHT (ZONING) | 15030 |
