West Park One - Building Sections (A401)

A401 Building Sections

Building Section 2

• Scale: 1:100
• Grid Lines: 1, 2, 3, 4, 5, 6, 7
• Key Features:
  • ELEVATOR HOISTWAY BEAM.
  • ELEVATOR OVERRUN.
  • PERIMETER DRAIN.
  • PARKADE WALL BELOW GRADE:
    • DRAINAGE MAT.
    • DAMPPROOFING.
    • CONCRETE.

Building Section 1

• Scale: 1:100
• Grid Lines: 1, 2, 3, 4, 5, 6, 7
• Floor Designations:
  • LEVEL 4
  • LEVEL 3
  • LEVEL 2
  • LEVEL 1
  • PARKADE LEVEL 1
  • PARKADE LEVEL 2

Building Elevations and Vertical Dimensions

Assembly Details

ROOF ASSEMBLY: (1 HOUR FIRE RATED)

• 2 PLY SBS ROOF MEMBRANE.
• COVER BOARD.
• TAPERED RIGID INSULATION AS REQUIRED TO ACHIEVE SLOPE TO DRAIN - SEE ROOF PLAN.
• R28 RIGID INSULATION.
• VAPOUR RETARDER.
• PLYWOOD SHEATHING.
• WOOD JOISTS.
• (2) LAYERS TYPE 'X' GYPSUM WALLBOARD.

LEVELS 2 - 4 FLOOR CEILING ASSEMBLY: (1 HR FIRE RATED)

• CONCRETE TOPPING.
• PLYWOOD SHEATHING.
• ACOUSTIC INSULATION BETWEEN WOOD JOISTS.
• RESILIENT METAL CHANNELS.
• (2) LAYERS TYPE 'X' GYPSUM WALLBOARD.

EXTERIOR WALL ASSEMBLY:

• SIDING - SEE EXTERIOR ELEVATIONS
• STRAPPING
• SEMI-RIGID INSULATION
• SELF-ADHERED AIR AND MOISTURE BARRIER
• WOOD FRAMING WITH MINERAL WOOL INSULATION
• VAPOUR RETARDER
• TYPE 'X' GYPSUM WALLBOARD

LEVEL 1 FLOOR ASSEMBLY:

• CONCRETE SLAB (2 HOUR FIRE RATED).
• SPRAY APPLIED FIBROUS INSULATION - SEE PARKADE REFLECTED CEILING PLAN.

SUSPENDED SLAB OUTSIDE BUILDING ENVELOPE:

• HARDSCAPE OR PLANTING - SEE ARCHITECTURAL SITE PLAN AND LANDSCAPE DRAWINGS.
• ROOT BARRIER
• DRAINAGE MAT
• SBS ROOF MEMBRANE
• CONCRETE SLAB (2 HR FIRE RATED).

LEVEL P1 FLOOR ASSEMBLY:

• TRAFFIC COATING.
• CONCRETE SLAB.

LEVEL P2 FLOOR ASSEMBLY:

• CONCRETE SLAB.
• REINFORCED POLYETHELYNE VAPOUR RETARDER.
• COMPACTED GRAVEL.

PARKADE WALL BELOW GRADE:

• DRAINAGE MAT.
• DAMPPROOFING.
• CONCRETE.
