West Park One - Building Sections (A402)
Additional building sections detailing the internal vertical structure and relation to site grading.
West Park One
Project Details
- Project: West Park One
- Client: West Park One Properties Ltd.
- Location: Victoria, BC
- Date: 03 JUN 2022
- Sheet Number: A402
- Scale: 1:100
Building Elevation Data
| Level | Elevation (m) | Vertical Dimension (mm) |
|---|---|---|
| TOP OF ROOF SHEATHING | 81.830 | 250 |
| L4 | 78.830 | 3000 |
| L3 | 75.770 | 3060 |
| L2 | 72.710 | 3060 |
| L1 MAIN FLOOR | 69.650 | 3060 |
| P1 | 66.460 | 3210 |
| P2 | 63.580 | 2880 |
Building Sections
The sheet contains three architectural building sections:
1. Building Section (Scale 1:100)
This section shows the internal structure of the building between grid lines A and E, highlighting the vertical circulation areas including the main stairwells. It details the floor plates from the P2 parking level up to the roof.
2. Building Section (Scale 1:100)
This section provides a view of the building's core, including the elevator shaft and stairs. It shows the rooftop mechanical unit located between grid lines B and C. The exterior site context is also depicted, including:
- Mechanical Unit: Located on the roof.
- Retaining Walls: Annotated with "SEE LANDSCAPE."
- Planting Area: Annotated with "SEE LANDSCAPE."
- Property Lines: Marked on both the left and right sides of the structure.
3. Building Section (Scale 1:100)
A section illustrating the overall building massing and floor divisions across grid lines A through E. This drawing includes the exterior stairs and the relationship of the building to the sloped grade on the right side of the property.
General Annotations:
- Grid lines are labeled A, B, C, D, and E.
- Property lines are indicated at the boundaries of the site.
