Appendix
West Park One - Unit Plans (A601)
July 19, 2022Page 652 sections
Detailed floor plans for specific suite types (A through F), showing internal layouts and square meterage.
Suite sizes range from 53 SM to 101 SMTypes include 1-bed, 1-bed + den, 2-bed, and 2-bed + den
West Park One
West Park One Properties Ltd. Victoria, BC 03 JUN 2022
Page 65
Unit Plans
A601 Scale 1:nn
Unit Plan Summary
| Unit Type | Configuration | Area |
|---|---|---|
| TYPE E-1 | 2 BED + DEN | 84 SM |
| TYPE E | 2 BED + DEN | 82 SM |
| TYPE C-1 | 1 BED + DEN | 69 SM |
| TYPE C | 1 BED | 53 SM |
| TYPE F | 2 BED + DEN | 101 SM |
| TYPE D | 2 BED | 85 SM |
| TYPE B | 2 BED | 77 SM |
| TYPE A | 2 BED | 75 SM |
Plan Details and Annotations
The individual unit plans include the following dimension annotations and equipment labels:
- TYPE C-1: Dimensions of 3000 and 1800.
- TYPE C: Dimensions of 3005 and 1995.
- TYPE F: Dimensions of 6058 and 1995.
- TYPE D: Dimensions of 3005 and 1995.
- TYPE A: Dimensions of 3695 and 3695.
- General Labels: Unit floor plans indicate locations for S (Stove), F (Fridge), DW (Dishwasher), and W/D (Washer/Dryer).
Page 65
