A015 STREET VIEW - EAST FACING
Street-level perspective rendering of the proposed building from the east.
Urban West Architecture
Vancouver 102-1688 West 1st Ave Vancouver BC V6J 1G1 T 604 603 1332
Victoria 2822 Prior Street Victoria BC V8T 3Y3 T 604 603 1332
Project Information
Portage Park Residences 167, 169 & 171 Island Highway, View Royal, BC Project No: 2021-01
Revisions
| NO. | DATE | DESCRIPTION |
|---|---|---|
| 2022 08 12 | REISSUED FOR DP | |
| 2022 07 12 | REISSUED FOR DP | |
| 2022 04 04 | ISSUED FOR DP | |
| 2022 01 13 | REISSUED FOR REZONING | |
| 2021 12 03 | ISSUED FOR REZONING |
General Notes
THIS DRAWING IS THE EXCLUSIVE PROPERTY OF URBAN WEST ARCHITECTURE INC., AND MAY NOT BE REPRODUCED, COPIED OR LOANED WITHOUT WRITTEN PERMISSION FROM URBAN WEST ARCHITECTURE INC. THIS DRAWING MUST NOT BE SCALED. THE GENERAL CONTRACTOR SHALL VERIFY ALL DIMENSIONS, DATUMS, AND LEVELS PRIOR TO COMMENCEMENT OF WORK. ALL ERRORS AND OMISSIONS MUST BE REPORTED IMMEDIATELY TO URBAN WEST ARCHITECTURE INC. THIS DRAWING IS TO BE USED IN CONJUNCTION WITH ALL OTHER DRAWINGS AND SPECIFICATIONS. THESE DRAWINGS ARE NOT VALID FOR CONSTRUCTION UNLESS REVISION DESCRIPTION INDICATES - ISSUED FOR CONSTRUCTION. ALL WORK TO COMPLY WITH MUNICIPAL STANDARDS.
Drawing Title
A015 STREET VIEW - EAST FACING
