ATTACHMENT 6 - LANDSCAPE CONCEPT PLAN

ATTACHMENT 6: PORTAGE PARK RESIDENCES - LANDSCAPE CONCEPT PLAN

Plan Details and Labels

• ACCESSIBLE GATE
• PATH CONNECTION
• CONCRETE WALKWAY
• SPECIAL PAVED PATIO
• PRIVACY SCREEN
• BLOCK RETAINING WALL (SEE NOTES)
• BLACK VINYL COATED CHAIN LINK FENCE (SEE DETAIL 1)
• CONIFER HEDGE
• PERIMETER WOOD FENCE
• STEPPING STONES
• SPECIAL PAVED PATIO
• PLANTER W/ TALL GRASSES
• FLOWER TREE IN ROUND POT
• CONCRETE PARKADE WALL
• WATERFALL FOUNTAIN FEATURE AT ENTRANCE
• BOARDWALK/BRIDGE
• ENTRANCE WALKWAY
• BENCH
• BIKE RACK
• QUIET PATIO W/ STAIRS TO AMENITY GARDEN
• GRASSES IN RAISED CONCRETE PLANTER
• BLOCK RETAINING WALL (SEE NOTES)
• VIEW
• LAWN
• INDENTATION IN PARKING GARAGE FOR TREE ABOVE
• STROLLING PATH
• NATIVE PLANT RESTORATION FOR PARK EDGE TRANSITION
• EXHAUST DOGHOUSE
• LARGE DECIDUOUS TREE
• INDENTATION IN PARKING GARAGE FOR TREE ABOVE
• BOARDWALK/BRIDGE
• PATIO WITH BENCH
• SOCIAL PAVILION C/W TABLES, CHAIRS, BBQ, & GREEN ROOF
• 4 LARGE DECIDUOUS TREES LOCATED IN PARK AREA c/w DRIP RING IRRIGATION
• ORNAMENTAL GRASSES
• EXISTING HYDRO KIOSK (REMOVAL TBD)
• STAMPED PAVED PARKING STALL
• CONCRETE WALKWAY
• PROJECT SIGN
• PLANTED RAIN GARDEN
• SIGN FOR PAVILLION ACCESS
• SIDEWALK AND GATE TO AMENITY AREA
• NEW PMT LOCATION W/ RIVER ROCK
• EXISTING FIRE HYDRANT
• EXISTING TREES IN GRASS BOULEVARD
• SOD LAWN
• PLANTED RAIN GARDEN
• CLASS 2 STREET TREE - INSTALL "DEEPROOT" BARRIER ADJACENT TO SERVICE LINE TO PROTECT INFRASTRUCTURE
• EXTENT OF DEEPROOT BARRIER

Planter Retaining Block Walls

• TYPE: MEVILLE TANDEM - LONG (WITH CAPSTONE)
• COLOUR: VICTORIAN
• SUPPLIER: ABBOTSFORD CONCRETE
• PHONE: 604-852-4967

Lighting Symbols

• BOLLARD LIGHTS (x25)
  • DESCRIPTION: LIGHT COLUMN PATHWAY BOLLARD
  • HEIGHT: 9.5"
  • CONTACT: FORMS + SURFACES
• RECESSED WALL LIGHTS (x8)
  • MODEL: L49 MA
  • FINISH: MATTE CLEAR ANODIZED
  • CONTACT: MP LIGHTING
• SUBMERSIBLE LIGHT (x3)
  • DESCRIPTION: LED POND AND LANDSCAPE SPOT LIGHT KIT
  • MODEL: 3W PRODUCT #84030
  • CONTACT: WES-TECH.
• DECORATIVE LIGHT pole (x4)
  • DESCRIPTION: CORDIA PEDESTRIAN
  • HEIGHT: 142"
  • CONTACT: FORMS + SURFACES

Softscape Legend

• LARGE DECIDUOUS SHADE TREE
• SMALL ORNAMENTAL DECIDUOUS TREES
• LARGE AND SMALL CONIFEROUS TREES
• LARGE SHRUB
• MEDIUM SHRUB
• SMALL SHRUB
• GROUND COVER & PERENNIALS
• TREES TO BE RETAINED
• TREES TO BE REMOVED

Grading Plan

• EXISTING GRADE (Dashed line)
• PROPOSED GRADE (Solid line)
• Key Elevations:
  • F.G. 14.7m
  • F.G. 14.1m
  • BOW 10.85m
  • TOW 14.3m
  • BOW 12.1m
  • FG 14.3m
  • EG 12.8m
  • FG 12.6m
  • EG 12.6m
  • TOW 14.4m
  • TOW 14.8m
  • FG 14.7m
  • EG 13.1m
  • EG 14.5m
  • EL 15.6m
  • FG 12.0m
  • EG 12.0m
  • EL 11.5m

Chainlink Fence Detail

[Diagram: Chainlink Fence Detail] NOTE: ALL METAL PIECES TO BE POWDERCOATED BLACK TO APPROVAL OF LANDSCAPE ARCHITECT.

• 1" O.D. TOP RAIL
• 3" O.D. TERMINAL POST
• CHAINLINK FABRIC BLACK VINYL COATED (HEAVY GUAGE).
• 1 1/4" TENSION BAR
• 1 1/4" TENSION WIRE
• 2" O.D. LINE POST
• 12" Ø 30 Mpa CONCRETE POST FOOTINGS SLOPE TOP TO DRAIN.
• 6" DRAIN ROCK
• COMPACTED SUBGRADE TO 98% S.P.D.
• ALL METAL FENCES TO BE ELECTRICALLY GROUNDED.

Suggested Plant List

Notes:

• All landscape work to conform with B.C.S.L.A. / B.C.N.T.A. standard specification.
• All areas to be irrigated with an automatic underground system.
