Attachment 3 - Site Plan

September 6, 2022Page 1471 section

A site plan drawing illustrating the existing patio area and the dimensions of the proposed pergola.

1 CALL TO ORDER

Proposed Pergola: 6.64 m x 4.9 m2.1 m setback from property line

Attachment 3

Site Plan - Chilco Road

Site plan for Lot 3 on Chilco Road, showing a dwelling under construction, an existing patio, and a proposed pergola. The diagram includes lot boundaries, proximity to a park, and specified required setbacks.

Property and Location Details:

Address: Chilco Road
Lot Number: 3
Adjoining Areas: Lot 2, Lot 4, and Park
Access: SAW 2.00m wide (14.797)

Development Specifications:

Current Status: Dwelling under construction
Existing Features: Existing Patio
Proposed Features: Proposed Pergola (6.64 m x 4.9 m)
Setbacks: Required Setbacks indicated by red dashed lines (including a 2.1 m setback)

Recorded Dimensions and Measurements:

Lot Boundaries: 27.085, 26.497, 14.785
Dwelling/Structure Segments: 16.30, 9.44, 3.65, 2.74, 3.20, 3.19, 1.37, 1.52, 0.64, 3.30
Setbacks and Spacing: 6.00, 5.25, 3.22, 3.12, 4.66, 3.18, 4.51, 3.20

Document Notes:

...s shown under construction
...ure is situate with respect to nearby
...document is prepared for the use of the
...for inspection purposes only.
...m of boundary or lot redefinition.
...mprovements shown.
