Appendix
Attachment 5 - Proposed install drawings
September 6, 2022Pages 150–1512 sections
Hand-drawn technical sketches of the proposed patio cover installation and roof mount bracket details.
22' x 16' V-pan patio coverSkylights included in designRoof mount detail includes I-beam with 2x6s
2446 LUND ROAD, VICTORIA, BC V9B 6W4
BEDASEE / BARBOSA
22' x 16' V-PAN PATIO COVER WITH 5 POSTS + 2 ROOF MOUNTS
Plan View Specifications:
- Dimensions: The cover measures 22' in width and 16' in depth
16' depth dimension line - Support Structure: The plan indicates 5 posts
Post marker - Beam Detail: 6 1/4" I-Beam with two 2x6s
Beam structural specification - Attachment: The unit is attached to the "HOUSE / ROOF"
House/roof label - Skylights: Three skylight sections are integrated into the cover , , .
- Slope: The slope is specified as 1/2" per LF (linear foot) .
- Drainage: A gutter is shown at the front edge of the structure .
Page 150–151
ROOF MOUNT DETAIL
The detail drawing illustrates the connection between the patio cover and the existing roof:
- Roof Bracket: The mounting hardware used to secure the structure .
- Patio Cover: The main cover structure attached to the mount .
- Structural Components: Shows the connection of the "I-BEAM WITH 2x6's" to the roof bracket on the existing roof.
Page 150–151
