ELEVATIONS

ELEVATIONS - INTERNAL COURT NORTH & SOUTH

Project Status: DP Scale: 1 : 100 DWG. NO: A225

KEYNOTE LEGEND

MATERIAL	DESCRIPTION
1	BRICK. COLOR: LIGHT GREY
2	FIBER CEMENT PANEL SYSTEMS. COLOR: WHITE
3	FIBER CEMENT PANEL SYSTEMS. COLOR: LIGHT GREY
4	FIBER CEMENT PANEL SYSTEMS. COLOR: DARK GREY
5	FIBER CEMENT PANEL. COLOR: CEDAR STAINED WOOD TEXTURE (HORIZONTAL)
6	CAST-IN-PLACE CONCRETE
7	ALUMINUM AND CLEAR GLASS GUARD. COLOR: CHARCOAL
8	VINYL WINDOW - FRAME COLOUR: CHARCOAL
9	VINYL FULL GLAZED SLIDING DOOR - FRAME COLOUR: IRON GRAY
10	METAL FRONT DOOR WITH GLASS PANELS. MATERIAL: ALUMINUM. COLOR: CEDAR STAINED WOOD
11	PRIVACY SCREEN: OBSCURED GLASS & METAL
12	WOOD ROOF FASCIA. PAINTED. COLOUR: CHARCOAL
13	OVERHEAD INSULATED GARAGE DOOR. METAL. COLOUR: CHARCOAL/WHITE (ALTERNATING)
14	TRELLIS AT SITE ENTRIES
15	PLAYGROUND EQUIPMENT

SUBMISSION

Date (YYYY-MM-DD)	Description
2022-06-06	Issued for Rezoning
2023-12-06	Issued for Rezoning

REVISION

No.	Date	Description

The following elevations show the internal court views for the proposed development, including buildings 1 through 5.

BUILDING 1, BUILDING 2 & BUILDING 3

This elevation view shows the north side of the internal court. It includes visitor parking, landscaping, and building facades with various materials as indicated in the keynote legend.

Upper floor and roof detail of townhouse units

Upper floor facade showing windows and wood texture siding

Facade detail showing panels and windows

Roof and upper floor architectural detail

Facade detail with white and grey panels and windows

Facade detail with windows and grey panels

Facade detail with windows and light grey panels

Upper level architectural detail with window

Facade detail showing cladding panels and window

Facade detail showing different material transitions

Facade detail showing windows and paneling

Ground floor detail showing a dark garage door and landscaping

Ground floor detail with alternating garage door colors and landscaping

Ground floor detail showing garage door and bushes

Ground level garage door and landscaping detail

BUILDING 4 & BUILDING 5

This elevation view shows the south side of the internal court. Building 3 is shown in outline to the left, and an outdoor amenity space with a playground is located to the right.

Upper floor facade with white panels and windows

Facade detail showing windows and wood texture cladding

Upper floor facade detail showing different cladding materials

Facade detail showing wood texture siding and white panels

Ground floor detail with a white garage door and shrubs

Ground floor detail with a dark garage door and green shrubs

Ground floor detail showing a front door and a white garage door

Ground floor detail of a front entrance door

Ground floor detail with a wood-finish front door and white garage door

Ground level detail with garage door and foundation

Ground level detail of a garage door and surrounding wall

Ground floor entry and garage facade detail

Ground level detail showing foundation and landscaping

Ground level wall and landscaping detail

Outdoor amenity space showing a colorful playground structure
