Attachment 5: Plan of Subdivision of the Remainder of Block 3, Plan 1688

June 17, 2025Page 251 section

A historical survey plan (Plan 34685) showing the layout of the lots on Tovey Crescent.

1 CALL TO ORDER
Dated October 1980Plan 34685

PLAN OF SUBDIVISION OF THE REMAINDER OF BLOCK 3, PLAN 1688 SECTION 8, ESQUIMALT DISTRICT

Scale: 1:500

Distances are in Metres unless otherwise indicated. Astronomic Bearings, derived from Plan 18970.

Legend

  • O.I.P Denotes iron post found
  • I.P. standard iron post set
Survey plan map for subdivision Plan 34685, showing the creation of Lots 1 through 8 along Tovey Crescent and a large remainder lot 9 (Area = 0.808 ha). The map identifies Tovey Crescent, View Royal Avenue (with areas dedicated for road), Bessborough Avenue, and a 3.0 Metre Lane. Adjoining properties include Plan 14797 and Plan 18970.
Survey plan map for subdivision Plan 34685, showing the creation of Lots 1 through 8 along Tovey Crescent and a large remainder lot 9 (Area = 0.808 ha). The map identifies Tovey Crescent, View Royal Avenue (with areas dedicated for road), Bessborough Avenue, and a 3.0 Metre Lane. Adjoining properties include Plan 14797 and Plan 18970.

Legal and Filing Information

PLAN 34685

Deposited in the Land Title Office of Victoria, B.C. this 28th day of October, 1980.

Approved under the Land Title Act this 3rd day of Oct, 1980. Approving Officer - Ministry of Transportation & Highways

This Plan lies within the Capital Regional District.

The registered owners designated hereon hereby declare that they have entered into a condition or covenant with her Majesty the Queen in right of the Province of British Columbia as represented by the Minister of Transportation & Highways under Section 215 of the Land Title Act.

Registered Owner: William Tytler Witness: Jean Pugh Address: 101 2626 Blackwood Vic B.C.

Registered Owner: Douglas Oliver Boardman Witness: Jean Pugh Address: #402 - 2626 Blackwood Address: 1905 LEYNS ROAD V.I.C. B.C. Occupation: CRANE OPERATOR

Surveyor's Certification

I, Michael Ecroyd Claxton, British Columbia land surveyor, of Victoria, in British Columbia, certify that I was present at and personally superintended the survey represented by this plan and that the survey and plan are correct. The survey was completed on the 12th day of May, 1980.

Michael E. Claxton B.C. Land Surveyor 822 Sevenoaks Road Victoria, B.C. 479-2258 File: 80-621

Page 25
