Council Meeting/Documents/ATTACHMENT 1: Concept Design
Appendix

ATTACHMENT 1: Concept Design

June 17, 2025Pages 37–382 sections

Technical drawings and illustrative designs for the proposed Phase 1 of the Watkiss Park project, including seating nodes and native plantings.

2 APPROVAL OF AGENDA
MDI Landscape ArchitectsPhase 1 and Phase 2 areasCircular Seating NodesToVR Symbol on Concrete

ATTACHMENT 1

Landscape Plan: Phase 1 and Phase 2

Topographical boundary lines and survey points at Watkiss Way
Topographical boundary lines and survey points at Watkiss Way
Plan view showing existing trees and proposed planting areas
Plan view showing existing trees and proposed planting areas
Label for Phase 2 Future Tree Planting Programs
Label for Phase 2 Future Tree Planting Programs
Topographical contour lines detail
Topographical contour lines detail
Plan area for Hydro SRW and meadow seeding
Plan area for Hydro SRW and meadow seeding
Label and path section for Galloping Goose Trail
Label and path section for Galloping Goose Trail
Labels for Existing Trees along Watkiss Way
Labels for Existing Trees along Watkiss Way
Plan reference for Anode bed
Plan reference for Anode bed
Detail of Phase 1 park area with seating node
Detail of Phase 1 park area with seating node
Topographical site line details
Topographical site line details
Circular seating node layout within Phase 1
Circular seating node layout within Phase 1
Landscape plan detail showing planting areas and pathways
Landscape plan detail showing planting areas and pathways
Survey data markers and elevation point TP 12.90
Survey data markers and elevation point TP 12.90
Detailed land contour lines
Detailed land contour lines
Topographical slope indicators
Topographical slope indicators
Existing Trees reference labels
Existing Trees reference labels
Label for Pole mounted anode bed kiosk
Label for Pole mounted anode bed kiosk

Plan Labels and Project Phases:

  • PHASE 1: CAPITAL PROJECT
  • PHASE 2: FUTURE PLAN FOR OTHER TREE PLANTING PROGRAMS - PREP LAND NOW
  • Anoda bed
  • Existing Trees
  • Area over and around Anode Bed is open with few modifications
  • Pole mounted anode bed kiosk
  • WATKISS WAY
  • GALLOPING GOOSE TRAIL
  • Hydro SRW
Page 37–38

Phase 1: Park Design

Phase 1: Park Design heading
Phase 1: Park Design heading
Park Design title detail
Park Design title detail
Park design plan view - north-west section
Park design plan view - north-west section
Park design plan view - Watkiss Way boundary
Park design plan view - Watkiss Way boundary
Plan detail of circular seating node with benches
Plan detail of circular seating node with benches
Plan view of seating area nodes 1 and 4
Plan view of seating area nodes 1 and 4
Plan detail showing 3:1 slope and meadow area
Plan detail showing 3:1 slope and meadow area

1.0 HARDSCAPE SURFACES

Legend for Hardscape Surfaces and plan detail of Anode bed area
Legend for Hardscape Surfaces and plan detail of Anode bed area
Item Type Description
1.1 Concrete Paving Cast in place, light broom finish. Sawcut control joints.
1.2 Aggregate Pathway CRD Path Mix - filter fabric under 3/4" crush.

3.0 SOFTSCAPE

Legend for Softscape items 3.1 to 3.4 and Site Furnishings
Legend for Softscape items 3.1 to 3.4 and Site Furnishings
Item Type Description
3.1 Planting Area - Tree & Shrub -300mm Depth, Shrub Growing Medium.
-Maintenance to meet CLS Level 3 "Moderate"
3.2 Slope Planting Pockets -Pockets of plants that will spread across slope over time. 300mm depth, Shrub Growing Medium
-Maintenance to meet CLS Level 4 "Functional"
3.3 Lawn Area -Add nutrients and seed with perennial rye grass blend to re-establish existing lawn.
-Maintenance to meet CLS Level 3 "Moderate"
3.4 Meadow Seeding -Retain existing lawn, seed with meadow mix in phase 2. Seed mix TBD.
-Maintenance to meet CLS Level 6 "Service & Industrial". Edges can be mowed or weed wacked as needed.

5.0 SITE FURNISHINGS

Legend for Site Furnishings item 5.3 and Fencing & Rails
Legend for Site Furnishings item 5.3 and Fencing & Rails
Item Type Description
5.1 Curved Bench -Wishbone 'Skyline Curved Bench'. 6 Sections per seating node, arranged into a circle
5.2 Bird House -Supplied by New Roads, maintained by Town of View Royal.
5.3 Educational Signage -TBD, possibility to include in future phase.

4.0 FENCING & RAILS

Item Type Description
4.1 Split Rail Fence Split Rail Fence

Reference Photos

Photo examples of Circular Seating Nodes and ToVR symbol graphics
Photo examples of Circular Seating Nodes and ToVR symbol graphics
Graphic of ToVR Symbol and photo example of Bird Houses
Graphic of ToVR Symbol and photo example of Bird Houses
Reference title for Native Planting and Gravel Path
Reference title for Native Planting and Gravel Path
Photo examples of Native Planting and a Gravel Path section
Photo examples of Native Planting and a Gravel Path section
Reference titles for Gravel Path, Lawn Area, and Split Rail Fence
Reference titles for Gravel Path, Lawn Area, and Split Rail Fence
Photo examples of a Gravel Path, Lawn Area, and Split Rail Fence
Photo examples of a Gravel Path, Lawn Area, and Split Rail Fence
  1. Circular Seating Nodes
  2. ToVR Symbol on Concrete
  3. Bird Houses
  4. Native Planting
  5. Gravel Path
  6. Lawn Area
  7. Split Rail Fence
