Council Meeting/Documents/Houston Sign Proposal - 1701 Island Highway
Appendix

Houston Sign Proposal - 1701 Island Highway

December 2, 2025Page 1132 sections

Technical proposal and site plans for new signage at 1701 Island Highway.

3.7 Square meters total per sign cabinetHeight of 4.8m / 15.74ft

Project Details

  • PROJECT: Client
  • DATE: 2025
  • DESIGNER: PROCIE
Page 113

Sign Proposal

Total Area: 3.7 Square meters total

Location and Site Reference

Street view photograph showing the current sign location at the intersection, with a height label of 4.8M / 15.74ft
Street view photograph showing the current sign location at the intersection, with a height label of 4.8M / 15.74ft
Aerial map showing the property location and site frontages: 63m / 207ft along Island Hwy and 106.6m / 350ft along Wilfert Rd
Aerial map showing the property location and site frontages: 63m / 207ft along Island Hwy and 106.6m / 350ft along Wilfert Rd

Description:

  • Double sided 1.52m x 2.43m LED illuminated sign cabinet
  • Flat polycarbonate sign face with flat cut vinyl graphics
  • Frame & cabinet painted black to match
  • Internal white LED illumination
  • Connected to supplied power at sign locations

Additional Notes:

  • OUR QUOTE INCLUDES (1) INITIAL DESIGN CONCEPT AND 1 REVISION TO THAT INITIAL DESIGN IF NEEDED.
  • ADDITIONAL DESIGN CHANGES, OUTSIDE OF WHAT IS ESTIMATED, WILL BE BILLED ACCORDINGLY.
  • PLEASE NOTE THAT COLOURS SHOWN ON A SCREEN MAY DIFFER FROM FINAL PRODUCT.
  • THIS SIGN PROPOSAL IS PROTECTED BY COPYRIGHT. ALL RIGHTS RESERVED BY HOUSTON SIGN 90 LTD.

CUSTOMER APPROVAL: ______________________________ DATE: _________________
