Attachment B

*Note: print may not be to scale

Architectural cross-section drawing titled "SECTION SEA TO STREET" showing the profile from Portage Inlet to Shoreline Drive, including a residential building with labeled levels and elevations.

Drawing Details: Section Sea to Street

The drawing illustrates a cross-section of the property from the water (Portage Inlet) to the street (Shoreline Drive).

Key Locations and Features:

Portage Inlet: Located at the far left of the section.
15m Restoration Zone: Indicated adjacent to the inlet.
Existing Grade: Shown as a dashed line following the terrain.
Residential Structure:
- Main Level: Elevation 6.84
- Living Level: Elevation 3.80
- Crawlspace
Shoreline Drive: Located at the far right of the section.
Edge of Pavement: Indicated near the street.

Measurements and Elevations (m):

Inlet/Grade points: 0.0, 0.3, 2.0, 2.4, 3.75, 4, 2.10
Building heights: 10.69, 9.59
Horizontal distances: 15m (restoration zone), 43.75, 3.75, 2.45, 6.45, 3.45, 3.50

Section Label: SECTION SEA TO STREET SCALE 1:200

Title Block Information

Design Firm: RONAN DESIGN 3075 COWIE ROAD HORNBY ISLAND RONANDESIGN@UNISERVE.COM 250.335.0168

Project Details:

Residence For: Mikaila Mauro & Jaylem Manhas
Site Address: 2818 Shoreline Drive, View Royal
Date: 11/14/23
Title: SECTION SEA TO STREET
Scale: 1:200
Sheet: A4.1

Copyright Notice: COPYRIGHT MATERIAL. DESIGN IS EXCLUSIVE PROPERTY OF RONAN DESIGN. DRAWINGS MAY NOT BE USED WITHOUT WRITTEN CONSENT. ALL DIMENSIONS TO BE VERIFIED ON SITE PRIOR TO COMMENCING WORK. DISCREPANCIES TO BE REPORTED IMMEDIATELY TO RONAN DESIGN.
