SUPPLEMENTAL DRAWING FOR DEVELOPMENT PERMIT 2022/09
Updated architectural elevation drawing from Hearth Architectural provided as supplemental information for the March 5 meeting.
BURGER KING RENOVATION
1681 Island Highway, View Royal, BC
5.1 MATERIALS FINISH PALETTE
| Code | Material | Details |
|---|---|---|
| P-1 | BURGER KING® Flaming Red Paint | Manufacturer: PPG Color: Custom BURGER KING® Flaming Red Location: Drive-Thru Red Canopy Contact: Kevin Lastacy (616) 335-3259 klastacy@ppg.com |
| P-2 | General Paint | Manufacturer: PPG Color: 1021-4 Diversion Location: Stucco Contact: Kevin Lastacy (616) 335-3259 klastacy@ppg.com |
| P-3 | Wood Tones Paint | Manufacturer: PPG Color: 1078-6 Cocoa Delight Location: Site Accents, Stucco Contact: Kevin Lastacy (616) 335-3259 klastacy@ppg.com |
| P-4 | Silver Band Paint | Manufacturer: PPG Color: 6-230 Leafing Silver Aluminum Location: Textured coated metal Contact: Kevin Lastacy (616) 335-3259 klastacy@ppg.com |
| GL-1 | Storefront | Manufacturer: GMP Glazing Color: Anodized Aluminum, Clear Glazing Location: Entry/Dining Description: Series 7000 Aluminum Window Wall System Contact: www.gmpglazing.com |
| Code | Material | Details |
|---|---|---|
| FRC-1 | Heritage Wood Textured Panels | Manufacturer: Nichiha Material: Fiber Cement Cladding Product: Vintage Wood Color: Faux Cedar Location: Heritage Tower, Kitchen Enclosure Contact: Andrew Briggs abriggs@nichiha.com |
| CS-1 | General Stucco Finish | Manufacturer: STD or approved equal Material: Stucco Color: P-2 Finish: Smooth Finish Description: Horizontal and vertical reveals to align with adjacent FRC-1 or Storefront |
| MTL-1 | Metal Screens | Material: Aluminum extruded metal Finish: 3M Wood Grain Vinyl Color: WG-1222 Location: Metal Screens Contact: Entera Branding 850.763.7982 |
| MTL-2 | Drive-Thru Red Canopy | Manufacturer: Berridge Material: Metal flat sheet roofing Color: P-1 Location: Drive-Thru Red Canopy Contact: Entera Branding 850.763.7982 |
| MTL-3 | Silver Band | Material: Light metal framing with PT plywood substrate wrapped in 30# felt and cladded with aluminum panels Color: P-4 Location: Drive-Thru Red Canopy |
Elevations
NORTH ELEVATION
- Scale: 3/32" = 1'-0"
- Key Annotations:
- higher parapet extension
- raised lower parapet
- metal canopy
- retain existing stone
- replace with conforming dt window
SOUTH ELEVATION
WEST ELEVATION
- Scale: 3/32" = 1'-0"
- Key Annotations:
- higher parapet extension
EAST ELEVATION
- Scale: 3/32" = 1'-0"
- Key Annotations:
- raised lower parapet
- higher parapet extension
Garden Grill Renovation Scheme
Project Information
- Project: BURGER KING RENOVATION, 1681 Island Highway, View Royal, BC
- Drawing Title: EXTERIOR CHARACTER
- Drawing No: A2
- Project No: 2133
- Date: aug 2022
- Scale: AS SHOWN
- Drawn By: hai
- Approved By: VJM
Revisions
| No. | Date | Details | By |
|---|---|---|---|
| 1 | oct 31 2022 | issued for dp | vjm |
| 2 | MAR 4 2024 | issued for dp | vjm |
BUILDER'S RESPONSIBILITY TO LAYOUT WORK
It is the Builder's responsibility to lay out & carry out the work as detailed in the contract documents. It is therefore necessary for the builder to pay very close attention to actual site dimensions, geometries and conditions which may vary from those assumed on the drawings.
Any discrepancies which the Builder discovers within the contract documents themselves or between the contract documents & site conditions, are to be discussed with the Architect immediately before proceeding with any work.
Written dimensions shall have precedence over scaled dimensions.
Copyright Reserved
This plan and design are, and at all times remain, the exclusive property of HEARTH architectural Inc. and may not be used or reproduced without written consent.
