Appendix
Color Sample Board and Exterior Materials
May 21, 2024Pages 89–943 sections
Visual guide to the exterior colors, materials, and lighting fixtures proposed for the development.
Benjamin Moore paint colors: Narragansett Green, Sea Haze, FlintJames Hardie siding productsOutdoor lighting fixtures are 'dark skies' friendly
Color Sample Board
(all colors Benjamin Moore)
Scheme 1-Block U, R
- Main Body: Narragansett Green HC-157, Templeton Gray HC 161, Cloud White CC-40
- Trim: Cloud White CC-40
- Fascia: Cloud White CC-40
- Garage Door: Cloud White CC-40
- Front Door: Cloud White CC-40
- Rock: K2-Pacific Asher
Scheme 2-Blocks T, S, V
- Main Body: Sea Haze 2137-50, Kendall Charcoal HC-166, Chelsea Gray HC-168, Flint AF-560
- Trim: Cloud White CC-40
- Fascia: Cloud White CC-40
- Garage Door: Flint AF-560
- Front Door: Cloud White CC-40
Block U
Page 89–94
Exterior Materials
| Material Heading | Material Specification |
|---|---|
| James Hardie- Plank |  |
| James Hardie -Board and Batton |  |
| Garage Door-North West Door Therma Tech T-108 | |
| Front Door-Trim Lite, Flush Glazed with Satin etched Glass |
- Roof Shingles: Owen's Corning, Duration, Onyx Black
- Soffits, Gutters & Downspouts: Aluminum, Kaycan, Black
- Flashings: Black
- Fascia Boards: Combed Spruce, Wood Tone
- Belly Bands: Combed Spruce, 2x12
- Window Trim: Combed Spruce, Wood Tone, 1x4
- Corner Boards: Combed Spruce, Wood Tone 1x4
- Hardi Plank: Fibre Cement Plank, James Hardie (4 and 6 inch exposure)
- Board and Batton: Fibre Cement Plank, James Hardie
- Garage Doors (Painted): Steel, Northwest Doors
- Front Posts: Combed Spruce, Wrapped
- Rear Patio: Exposed Concrete, ICL, Gray
Page 89–94
Exterior Lighting
Placed around front door and garage
WEST Outdoor Light
- Model: CAN IOL283-BK
- Color: Black
- Type: Outdoor 1 Light
- Glass: Watermark Glass
- Bulb: 100W Type A Bulb
- Feature: Down Light
