Appendix
Revised Landscape Masterplan and Plan - April 2024
May 21, 2024Pages 111–1122 sections
Updated landscaping plans featuring additional garden beds and rearranged tree placements.
Dated April 14, 2024Includes specific notations for solid privacy fences
Sheet L-01: Landscape Masterplan
General Notes
- All landscape materials and construction to meet or exceed the Canadian Landscape Standard, latest edition.
- Contractor to protect existing trees and vegetation (unless otherwise mentioned) during construction.
- Permit may be required for trees to be removed.
- Install 3" diameter irrigation sleeving under new paving and through walls (below grade) such that all planting beds are accessible for irrigation/lighting. Flag ends of each sleeve.
- Install drainage sleeving where required by drainage plan (By others).
Planting Notes
- Tree placement and selection to be approved by landscape designer prior to planting.
- All existing plants to be retained are to be protected during installation and construction.
- Unless noted otherwise on planting plan, minimum soil depths are to be: 12" in lawn; 18" in groundcover and shrub areas. Each rootball to have one cubic yard of soil distributed to depth of 24" around the tree.
- All new trees to be planted as per BCLNTA standards.
- Lawn to be approved seed mix or approved sod.
- Soil mix in lawn areas to comply with Canadian Landscape Standard specifications.
- All planting beds to be bermed up minimum 4" above adjacent lawn or hard surface areas, except around existing trees. Existing trees are not to have grades adjusted around them.
- All plants to come from SOD free (Sudden Oak Death or Phytophthora ramorum) certified nursery.
- Any substitutions must be approved by landscape designer prior to ordering.
- Automatic irrigation system to be designed and installed by qualified professional. To IIABC standards and to cover all planted areas.
- Irrigation sleeves to be installed under all driveways, and retaining walls, and to all planting areas.
[Landscape Masterplan diagram showing residential lot layout with Blocks R, S, T, U, and V, property lines, and landscape elements like patios, lawn areas, and trees.]
Project Information
- Project: Limona Holdings, TLC Subdivision, View Royal, BC
- Drawing Title: West Park at Thetis Lake - Phase 5 - Landscape Masterplan
- Drawn By: KMZ
- Checked By: KMZ
- Date: April 14, 2024
- Scale: 1:200
- Sheet: L-01
Page 111–112
Sheet L-02: Landscape Planting Plan
General Notes
- All landscape materials and construction to meet or exceed the Canadian Landscape Standard, latest edition.
- Contractor to protect existing trees and vegetation (unless otherwise mentioned) during construction.
- Permit may be required for trees to be removed.
- Install 3" diameter irrigation sleeving under new paving and through walls (below grade) such that all planting beds are accessible for irrigation/lighting. Flag ends of each sleeve.
- Install drainage sleeving where required by drainage plan (By others).
Planting Notes
- Tree placement and selection to be approved by landscape designer prior to planting.
- All existing plants to be retained are to be protected during installation and construction.
- Unless noted otherwise on planting plan, minimum soil depths are to be: 12" in lawn; 18" in groundcover and shrub areas. Each rootball to have one cubic yard of soil distributed to depth of 24" around the tree.
- All new trees to be planted as per BCLNTA standards.
- Lawn to be approved seed mix or approved sod.
- Soil mix in lawn areas to comply with Canadian Landscape Standard specifications.
- All planting beds to be bermed up minimum 4" above adjacent lawn or hard surface areas, except around existing trees. Existing trees are not to have grades adjusted around them.
- All plants to come from SOD free (Sudden Oak Death or Phytophthora ramorum) certified nursery.
- Any substitutions must be approved by landscape designer prior to ordering.
- Automatic irrigation system to be designed and installed by qualified professional. To IIABC standards and to cover all planted areas.
- Irrigation sleeves to be installed under all driveways, and retaining walls, and to all planting areas.
Plant Schedule
| ID | Quantity | Latin Name | Common Name | Category | Scheduled Size | Mature Height | Mature Spread | Notes |
|---|---|---|---|---|---|---|---|---|
| AROG | 6 | Acer rubrum 'October Glory' | October Glory red maple | Tree | 6cm caliper; B&B | 40' (12m) | 25' (7.5m) | 22" (0.5m) diameter rootball at planting |
| CE | 2 | Cornus 'Eddies White Wonder' | Dogwood tree | Tree | 6 cm caliper; B&B | 35' (10.5m) | 20' (6m) | 22" (0.5m) diameter rootball at planting |
| GP | 2 | Ginkgo biloba 'Princeton Sentry' | Columnar maidenhair tree | Tree | 6cm caliper; B&B | 40' (12m) | 15' (4.5m) | 22" (0.5m) diameter rootball at planting |
| QG | 2 | Quercus garryana | Gary oak | Tree | 6cm caliper; B&B | 80' (24m) | 75' (22m) | 22" (0.5m) diameter rootball at planting |
| f | 7 | Fuchsia Mrs Popple | Hardy fuchsia | Shrub | #1 pot | |||
| Gs | 50 | Gaultheria shallon | Salal | Shrub | #2 pot | |||
| Mn | 19 | Mahonia nervosa | Cascade oregon grape | Shrub | #1 pot | |||
| Rar | 2 | Rhododendron 'Anna Rose Whitney' | Anna Rose Whitney rhododendron | Shrub | #3 pot | |||
| Rh | 4 | Rhododendron Wine and Roses | Wine and roses rhododendron | Shrub | #5 pot | |||
| Rn | 4 | Rhododendron 'Nova Zembla' | Pink rhododendron | Shrub | #5 pot | |||
| Rs | 16 | Ribes sanguineum 'King Edward' | Red flowering currant | Shrub | #3 pot | |||
| Sa | 15 | Symphoricarpos albus | Snowberry | Shrub | #5 pot | |||
| Sh | 48 | Sarcococca hookeriana humilis | Himalayan sweet box | Shrub | #2 pot | |||
| Sp | 5 | Spiraea japonica 'Goldflame' | Japanese Spirea | Shrub | #2 pot | |||
| V | 16 | Vaccinium ovatum | Evergreen huckleberry | Shrub | #2 pot | |||
| b | 20 | Bergenia 'Bressingham Ruby' | Elephant's ears | Perennial | #1 pot | |||
| cp | 6 | Carex testacea 'Prairie Fire' | Prairie fire sedge | Perennial | #1 pot | |||
| d | 20 | Dryopteris erythrosora | Autumn fern | Perennial | #1 pot | |||
| l | 39 | Lavandula angustifolia 'Munstead' | English lavender | Perennial | #1 pot | |||
| p | 83 | Polystichum tsus-simense | Korean rock fern | Perennial | #1 pot | |||
| pc | 161 | Parahebe catarractae - Blue Form | Blue parahebe | Perennial | #1 pot | |||
| pl | 48 | Pennisetum 'Little Bunny' | Dwarf fountain grass | Perennial | #1 pot | |||
| pm | 43 | Polystichum munitum | Western sword fern | perennial | #2 pot | |||
| r | 4 | Rudbeckia 'Goldsturm' | Black eyed Susan | Perennial | #1 pot |
[Landscape Planting Plan diagram showing specific planting locations and quantities for residential lot blocks R, S, T, U, and V.]
Project Information
- Project: Limona Holdings, TLC Subdivision, View Royal, BC
- Drawing Title: West Park at Thetis Lake - Phase 5 - Landscape Planting Plan
- Drawn By: KMZ
- Checked By: KMZ
- Date: April 14, 2024
- Scale: 1:200
- Sheet: L-02
Page 111–112
