Site Plan Of: Lot 6, Block 4, Section 8, Esquimalt District, Plan 1688

April 4, 2023Page 881 section

Legal survey plan for the waterfront property at 302 Bessborough Avenue showing existing structures and property boundaries.

8.1b Environmental Development Permit with Variance 2022/11 - 302 Bessborough Avenue
302 Bessborough AvenueJanuary 19, 2023PID: 007-085-133

Site Plan Of: Lot 6, Block 4, Section 8, Esquimalt District, Plan 1688

P.I.D. 007-085-133

Scale = 1:200 Dated this 19th day of January, 2023.

  • Distances and elevations shown are in metres.
  • Elevations are based on geodetic datum CVD28BC and derived from View Royal OCM VR06-10.
  • This site plan is for building and design purposes and is for the exclusive use of our client.
  • This document shows the relative location of the surveyed structures and features with respect to the boundaries of the parcel described above. This document shall not be used to define property lines or property corners.
Site plan of Lot 6, House #302, bounded by Bessborough Avenue to the northwest and Helmcken Bay to the southeast, including topographical details, structures, trees, and neighboring Lots 5 and 7.
Site plan of Lot 6, House #302, bounded by Bessborough Avenue to the northwest and Helmcken Bay to the southeast, including topographical details, structures, trees, and neighboring Lots 5 and 7.

Wey Mayenburg Land Surveying Inc. www.weysurveys.com #4-2227 James White Boulevard Sidney, BC V8L 1Z5 Telephone (250) 656-5155 File: 2300078\SIT\NO

The subject property is affected by the following registered documents: 92442G
