Council Meeting/Documents/Attachment 4: Proposed Exterior Treatment Materials Board
Appendix

Attachment 4: Proposed Exterior Treatment Materials Board

May 2, 2023Pages 55–584 sections

Detailed visual guide to the exterior cladding, windows, and fixtures for the proposed development.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:00 p.m.
Ceraclad Cladding - Zen Garden CharcoalHardie Panel - Rich EspressoVinyl Window - White and Black FramesRock Wall from Site Blast

ERSKINE LANE RE-DEVELOPMENT

PROPOSED EXTERIOR TREATMENT

Address: 7 ERSKINE LANE, TOWN OF VIEW ROYAL, B.C.
Scale: NTS
Project Number: 2017-05
Development Permit Date: 2023-01-25

Material Samples

1. Ceraclad Cladding – Zen Garden “Charcoal”
1. Ceraclad Cladding – Zen Garden “Charcoal”
2. Hardie Panel - Rich Espresso smooth finish
2. Hardie Panel - Rich Espresso smooth finish
3. Hardie Panel – Arctic White smooth finish
3. Hardie Panel – Arctic White smooth finish
4. Hardie Plank – Fisher Truegrain Series “Cedartone”
4. Hardie Plank – Fisher Truegrain Series “Cedartone”
7, 11. Storefront Door and Vinyl Window with Black Frame
7, 11. Storefront Door and Vinyl Window with Black Frame
10. Vinyl Window with White Frame
10. Vinyl Window with White Frame
19. Ceraclad Facia—Contemporary Smooth “Silver Grey”
19. Ceraclad Facia—Contemporary Smooth “Silver Grey”

Material Schedule

  1. Ceraclad Cladding – Zen Garden “Charcoal”
  2. Hardie Panel - Rich Espresso smooth finish with colour matched Alum Reveals
  3. Hardie Panel – Arctic White smooth finish with colour matched Alum Reveals
  4. Hardie Plank – Fisher Truegrain Series “Cedartone”
  5. Hardie Board/Plank Painted – To match Kaycan Charcoal Metal Facia
  6. Metal Facia – Kaycan Charcoal
  7. Storefront Door/Glazing – Black Frame
  8. Metal Door – To match Kaycan Charcoal Metal Facia
  9. Security Grille – Black
  10. Vinyl Window – White Frame
  11. Vinyl Window – Black Frame
  12. Glazed Aluminium Guards – Black with clear glass
  13. Picket Aluminium Guards – Black
  14. Glazed Aluminium Privacy Screen – Frosted glass
  15. Exposed Concrete
  16. Vine Covered Concrete Wall
  17. Exposed blasted Rockface
  18. Rock Wall from Site Blast
  19. Ceraclad Facia—Contemporary Smooth “Silver Grey”
Page 55–58

ERSKINE LANE RE-DEVELOPMENT

EAST AND SOUTH ELEVATIONS

Address: 7 ERSKINE LANE, TOWN OF VIEW ROYAL, B.C.
Scale: 1:100
Project Number: 2017-05
Development Permit Date: 2023-01-25

1 EAST ELEVATION

East Elevation - Upper section rendering
East Elevation - Upper section rendering
East Elevation - Lower section and site grade rendering
East Elevation - Lower section and site grade rendering

2 SOUTH ELEVATION

South Elevation - Upper section rendering
South Elevation - Upper section rendering
South Elevation - Lower section and main entrance rendering
South Elevation - Lower section and main entrance rendering

MATERIAL SCHEDULE

SYMBOL MATERIAL
1 CERACLAD CLADDING - ZEN GARDEN "CHARCOAL"
2 HARDIE PANEL - RICH ESPRESSO SMOOTH FINISH W/ COLOUR MATCHED ALUM REVEALS
3 HARDIE PANEL - ARCTIC WHITE SMOOTH FINISH W/ COLOUR MATCHED ALUM REVEALS
4 HARDIE PLANK FISHER TRUEGRAIN SERIES "CEDARTONE"
5 HARDIE BOARD/PLANK PAINTED - GREY
6 METAL FASCIA - GREY
7 STOREFRONT DOOR/GLAZING - BLACK
8 METAL DOOR - GREY
9 SECURITY GRILLE - BLACK
10 VINYL WINDOW - WHITE
11 VINYL WINDOW - BLACK
12 GLAZED ALUM GUARD - BLACK
13 PICKET ALUM GUARD - BLACK
14 GLAZED ALUM PRIVACY SCREEN - FROSTED GLASS
15 EXPOSED CONCRETE
16 VINE COVERED CONCRETE WALL
17 EXPOSED BLASTED ROCKFACE
18 ROCK WALL FROM SITE BLAST
19 CERACLAD FACIA - CONTEMPORARY SMOOTH SILVER GREY
Page 55–58

ERSKINE LANE RE-DEVELOPMENT

WEST AND NORTH ELEVATIONS

Address: 7 ERSKINE LANE, TOWN OF VIEW ROYAL, B.C.
Scale: 1:100
Project Number: 2017-05
Development Permit Date: 2023-01-25

1 WEST ELEVATION

West Elevation - Upper section rendering
West Elevation - Upper section rendering
West Elevation - Lower section, secondary entrance, and site grade rendering
West Elevation - Lower section, secondary entrance, and site grade rendering

2 NORTH ELEVATION

North Elevation - Upper section rendering
North Elevation - Upper section rendering
North Elevation - Lower section and site grade rendering
North Elevation - Lower section and site grade rendering

MATERIAL SCHEDULE

SYMBOL MATERIAL
1 CERACLAD CLADDING - ZEN GARDEN "CHARCOAL"
2 HARDIE PANEL - RICH ESPRESSO SMOOTH FINISH W/ COLOUR MATCHED ALUM REVEALS
3 HARDIE PANEL - ARCTIC WHITE SMOOTH FINISH W/ COLOUR MATCHED ALUM REVEALS
4 HARDIE PLANK FISHER TRUEGRAIN SERIES "CEDARTONE"
5 HARDIE BOARD/PLANK PAINTED - GREY
6 METAL FASCIA - GREY
7 STOREFRONT DOOR/GLAZING - BLACK
8 METAL DOOR - GREY
9 SECURITY GRILLE - BLACK
10 VINYL WINDOW - WHITE
11 VINYL WINDOW - BLACK
12 GLAZED ALUM GUARD - BLACK
13 PICKET ALUM GUARD - BLACK
14 GLAZED ALUM PRIVACY SCREEN - FROSTED GLASS
15 EXPOSED CONCRETE
16 VINE COVERED CONCRETE WALL
17 EXPOSED BLASTED ROCKFACE
18 ROCK WALL FROM SITE BLAST
19 CERACLAD FACIA - CONTEMPORARY SMOOTH SILVER GREY
Page 55–58

ERSKINE LANE RE-DEVELOPMENT

CONCEPT VIEWS

Address: 7 ERSKINE LANE, TOWN OF VIEW ROYAL, B.C.
Scale: NTS
Project Number: 2017-05
Development Permit Date: 2023-01-25

  1. View from Erskine Lane at west property line
    Close-up concept rendering of building facade
    Close-up concept rendering of building facade
  2. View from Erskine Lane at main building entry
    Concept rendering of building entrance and hillside
    Concept rendering of building entrance and hillside
  3. View from Erskine Lane at parking entry
  4. View from west end of Erskine Lane.
    Concept rendering of building perspective from west end
    Concept rendering of building perspective from west end
  5. View from Highway.
  6. View from Hospital.
Page 55–58

Document Images

(7)
10. Vinyl Window with White Frame

10. Vinyl Window with White Frame

5, 8. Painted Hardie Board/Plank and Metal Door to match Kaycan Charcoal

5, 8. Painted Hardie Board/Plank and Metal Door to match Kaycan Charcoal

9, 12, 13, 14. Security Grille, Glazed and Picket Aluminium Guards, and Glazed Aluminium Privacy Screen

9, 12, 13, 14. Security Grille, Glazed and Picket Aluminium Guards, and Glazed Aluminium Privacy Screen

Document image
Document image
Document image
Document image
