L 5.2 Planting Plan - List - Ref-images

July 4, 2023Page 413 sections

Reference image list and blooming schedule for the proposed plant species at 2820 Shoreline Drive.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:00 p.m.

Saskatoon berry (Amelanchier alnifolia)Douglas FirDecember 8, 2022

GENERAL PROJECT NOTES

The contractor shall notify Underground Services Alert at least 48 hours prior to any excavation on this project.
The contractor shall be responsible for the verification of all existing utilities in the field and for familiarizing himself/herself with all existing underground conditions prior to construction. Locations shown on the plans are approximate and for general information only.
Contractor is responsible for repairing and replacing at his/her expense any structures, fences, walls or plant life damaged or destroyed by his/her construction operations, on adjacent properties and/or anywhere outside the contract limit lines. Damaged items will be restored to original condition and to the satisfaction of the engineer.
All dimensions, elevations and existing conditions shall be checked and verified on the project site by the contractor and each trade before work begins. Errors and omissions and discrepancies shall be brought to the architect’s attention before construction begins or immediately as identified.
Provide all labor, materials, equipment, tools, transportation, utilities and other services and related tasks necessary for the construction as required by the contract documents.
Contractor shall assume sole responsibility for job site conditions and comply with safety regulations and restrictions as required for workers and pedestrians protection during the course of construction of this project.
All work shall be performed in conformance with all local, Provincial, and National codes, laws, ordinances, and regulations applicable. Nothing in the contract documents is to be construed to permit work not conforming to these codes, laws, ordinances, and regulations.
All new hardscape surfaces shall maintain a minimum 1.5% cross slope away from structures and walls as shown on Plan. All softscape surfaces shall maintain 2% slope away from structures and walls. Contractor shall ensure positive drainage throughout project area.
Contractor shall advise on installation of drainage features such as drain inlets, drain lines, and French drains if necessary to ensure positive drainage throughout project area. Refer to Grading + Drainage Plans by Civil Engineer.
Contractor is responsible to provide layout of all work for approval by Landscape Designer prior to proceeding with work.
Contractor to come up with an irrigation plan in collaboration with Landscape Designer. Final proposal to be approved by landscape designer.
Do not scale from this drawing
In case of discrepancies in the drawing , contact the designer

Page 41

DRAWING INDEX

L 1.0 Site Plan
L 1.1 Material Specification
L 2.0 - 4 Details
L 3.0 Lighting Plan + Lighting Specifications
L 5.0 Tree Plan - Planting Plan
L 5.1 Planting Plan - list - Ref-images
L 6.1 Development Permit Schematic

TREES / CONIFERS

Botanical name	Common name	code
Cedrus deodora ‘Pendula’	Weeping deodar cedar	C Cedr
Picea Omorika 'berliner's weeper’	Serbian Spruce 'berliner's weeper’	C Pic b
Picea omorika 'Pendula'	Weeping Serbian spruce	C Pic p
Pinus contorta	Shore Pine	C Pin
Pseudotsuga menziesii	Douglas Fir	C Pseu
Sequoiadendron giganteum 'Pendulum'	Weeping giant sequoia	C Seq

SHRUB

Native	Botanical name	Common name	code	Flower color
N	Amelanchier alnifolia	Saskatoon berry	H Amal	White
N	Philadelphus lewisii	Mock Orange	H Phil	White
	Buddleja alternifolia	Weeping butterfly bush	H Bud	Lila
N	Rosa nutkana	Nootka Rose	H Ros N	Pink
	Cotinus Coggygria ‘Young lady’	Smoketree	H Cotin
	Spirarea nipponica	Snowbound Spirea	H Spir	White
N	Salix scouleriana	Scouler's willow	H Salix s
N	Salix hookeriana	Hooker's willow	H Salix h
N	Salix purpurea ‘Nana’	Artic Willow	H Salix p
	Rosa sneewittchen	White shrub rose	H Ros s	White
N	Rubus parviflorus	Thimbleberry	H Rub	White
N	Gaultheria shallon	Salal	H Sal	White

CLIMBING PLANTS

Native	Botanical name	Common name	code	Flower color
	Clematis ‘Blue Boy’	Clematis	K1	Blue
	Clematis ‘Willy’	Clematis	K2	Pink
	Clematis type 3 \| select by client	Clematis	K3
N	Lonicera hispidula	Pink Honeysuckle	K4	Purple-red
	Rosa ‘New Dawn’	Cultivated Climbing Rose	K5	White-pink
	Rosa \| select by client	Cultivated Climbing Rose	K6

GRASSES

Native	Botanical name	Common name	code
N	Agrostis scabra	Hair Bentgrass	Gr Agr \| Matrix 1
	Calamagrostis brachytricha	Feather Reed Grass	Gr Call
	Carex Pansa	Sand dune Sedge	Gr Carex \| Matrix 1
N	Deschampsia cespitosa ssp. beringensis	Turfed hair grass	Gr Desh \| Matrix 1
	Molinia arundinacea ‘Skyracer'	Purple moor grass	Solo - see symbol drawing
	Sesleria autumnalis	Autumn Moor Grass	Gr Ses

PERENNIALS

Native	Botanical name	Common name	code	Flower color
N	Achillea millefolium	Common Yarrow	Solo - see symbol drawing	White
N	Achlys triphylla	Vanilla leaf	P Achlys	White
	Aquilegia vulgaris	Columbine	Solo - see symbol drawing	Purple-pink
N	Cornus canadensis	Bunchberry, Dwarf Dogwood	P Corn \| Matrix 3	White
N	Fragaria chiloensis	Coastal strawberry	P Frag c \| Matrix 2	White
N	Fragaria vesca	woodland strawberry	P Frag v \| Matrix 2	White
	Geranium Orion / pratense		Solo - see symbol drawing	Blue-lila
N	Maianthemum dilatatum	false lily-of-the-valley	P Maia \| Matrix 3	White
N	Maianthemum stellatum	star-flowered false Solomon’s-seal	Solo - see symbol drawing	White
N	Oxalis oregana	Redwood sorrel	P Oxal \| Matrix 3	White-pink
	Sanguisorba officinalis	Burnet	Solo - see symbol drawing	Wine red
N	Trillium ovatum	Western trillium	P Tril \| Matrix 3	White
	Verbena bonariensis	Brazilian Verbena	Solo - see symbol drawing	Lila-purple
	Veronicastrum virginicum ‘Lavendelturn’	Culvers root	Solo - see symbol drawing	Pink

FERNS

Botanical name	Common name
Polystichum munitum	Sword fern

BULBS

Native	Botanical name	Common name	Flower color
N	Allium cernuum	Nodding Onion	Pink
	Allium siculum	Sicilian honey garlic	Pink-white
	Allium sphaerocephalon	Round headed allium	Purple
	Eremurus robustus	White foxtail lily	Salmon
N	Triteleia hyacinthina	Hyacinth Brodiaea	White
