Council Meeting/Documents/Plan of Zoning Boundary Adjustment - Highland Pacific Golf Course
Appendix

Plan of Zoning Boundary Adjustment - Highland Pacific Golf Course

June 20, 2023Page 601 section

A technical survey plan showing the proposed rezoning boundary on the Highland Pacific Golf Course property.

9.2.a) Email dated June 13, 2023 from K. Bourgeois, District of Saanich, Re: District of Saanich Referral - 450 Creed Road
Lot A, Section 19, Plan VIP78109J.E. Anderson & AssociatesReceived May 10, 2023

Plan of Zoning Boundary Adjustment

HIGHLAND PACIFIC GOLF COURSE

Legal Description: LOT A, SECTION 9, PLAN VIP78109 PID: 026-153-921 Address: 450 CREED ROAD, VICTORIA BC Drawn By: AM Date: 20230429 Our File: 34455 Rev:

J.E. ANDERSON & ASSOCIATES SURVEYORS - ENGINEERS

Site Plan and Key Plan for Highland Pacific Golf Course boundary adjustment
Site Plan and Key Plan for Highland Pacific Golf Course boundary adjustment

SITE PLAN

Scale: 1:500

Site Plan Annotations:

  • EXISTING GROUND ELEVATIONS AT BOUNDARY CORNER (TYP.)
  • TOP OF BANK
  • TOE OF BANK
  • EXISTING ASPHALT
  • PROPOSED REZONING BOUNDARY
  • Lot A, Plan VIP78109, 026-153-921

KEY PLAN

Scale: NTS

  • Note: Site location indicated on aerial map.
Page 60
