Council Meeting/Documents/Attachment 3. Site Plan
Appendix

Attachment 3. Site Plan

March 3, 2015Page 1852 sections

A detailed technical site plan for the proposed 102 Atkins Road development, showing buildings, hard surfaces, and green space.

1 CALL TO ORDER
102 Atkins Road57% Green SpaceScale 1:250

EN VIRO TEC GENERAL CONTRACTING LTD.

Attachment 3

Site Plan

Detailed site plan for 102 Atkins Road showing building footprints (orange), hard surfaces (grey), and green space (green) with legal descriptors and elevation points.
Detailed site plan for 102 Atkins Road showing building footprints (orange), hard surfaces (grey), and green space (green) with legal descriptors and elevation points.
Category Area Percentage
Buildings 983 m² 15%
Hard Surfaces 1898 m² 28%
Green Space 3766 m² 57%
Total Site Area 6647 m² 100%

development permit

102 ATKINS ROAD VIEW ROYAL B.C.

  • drawing #: 7548
  • scale: 1:250
  • drawn by: JDF
  • Date: 11/9/14

VICTORIA DESIGN GROUP #103 891 ATTREE AVENUE VICTORIA, B.C. V9B 0A6 PH: 250.382.7374 FAX: 250.382.7364

Plan Notes and Labels:

  • (Galloping Goose)
  • Rem. 6 Plan 748 (Plan 1205 OS)
  • Parcel A DD L2503
  • Chilco
Page 185

102 atkins road DEVELOPMENT PERMIT

Page 185
