Council Meeting/Documents/Attachment II – Concept Plan
Appendix

Attachment II – Concept Plan

March 3, 2015Page 1911 section

A schematic concept plan showing the proposed building footprint layout along the Atkins Road parcel.

1 CALL TO ORDER

Tentative Plan

En Viro Tech

Part A of VIP 53139 of Lot 8 Section 98, Esquimalt District, Plan 748

J.E. Anderson & Associates Surveying - Engineering

Scale: 1:500 Date: July 24, 2014

All information is approximate
For discussion purposes only
All dimensions are in metres

Concept plan map showing a series of proposed building footprints on a parcel of land situated between Chilco Road, Atkins Road, and the E&N Railway line.
Concept plan map showing a series of proposed building footprints on a parcel of land situated between Chilco Road, Atkins Road, and the E&N Railway line.

Map Labels and Descriptions:

  • Chilco Road
  • Atkins Road
  • Parcel A VIP 53139
  • Part Section 98 E&N Railway
  • Existing Manor
  • Plan 748 (Part Lot 10)
Page 191
Extracted from: 2015 03 03 Council Agenda
