Tree Location Diagram (Topographic Site Plan)

Topographic Site Plan Of: Lot A, Section 8, Esquimalt District, Plan VIP71776

Scale: 1:500

Notes:

This document is prepared for municipal purposes only.
Dated this 28th day of October, 2014.
Distances and elevations shown are in metres.
Elevations are based upon geodetic datum derived from View Royal Central Monuments.

Topographic site plan map showing lots SL 1 through SL 7, common property, and surrounding parcels including Bishan Place and Jedburgh Road.

Property Details and Features

The site plan identifies the following subdivided lots (SL) and their respective areas:

SL 1: 636 Sq.m
SL 2: 512 Sq.m
SL 3: 578 Sq.m
SL 4: 629 Sq.m
SL 5: 629 Sq.m
SL 6: 629 Sq.m
SL 7: 880 Sq.m (Contains an existing House, Carport, and Pump Station)

Common Property:

Includes a main driveway access connecting from Jedburgh Road and extending through the site.

Surrounding Properties and Features:

Lot 6 Plan 45153
Bishan Place
Lot 3 (44877)
Lot 2
Lot 1
Jedburgh Road
Lot 1 Plan 46640
Rem. Lot A Plan 19042
Lot B Plan VIP71776
Lot 1 Plan 43429
Lot A Plan VIP88427
Lot B Plan VIP88427
SL 7 Plan VIS5234
E & N Railway Plan VIP66676
Lot A
Utilities noted: Utility Pole, Pump Station, Edge of Pavement.

Way Mayenburg Land Surveying Inc. www.waysurveys.com #4-2227 James White Boulevard Sidney, BC V8L 1Z5 Telephone (250) 656-5155 File: 14030401TOP.DWG
