TREE PROTECTION FENCING Detail Drawing E105

March 17, 2015Page 551 section

Technical drawing and specifications for construction of tree protection barriers on site.

8.1a Development Variance Permit No. 2015/02 - 17A Jedburgh Road
1.20m height requirementOrange snow-fencing mesh with wood frame

TREE PROTECTION FENCING

Technical detail drawing of tree protection fencing specifying a 1.20m height above ground, 600mm depth below ground, and a 2.4m maximum span between posts. The diagram labels include a 38 x 89mm top rail, 38 x 89mm bottom rail, 38 x 89mm posts, and ties or staples to secure the mesh.
Technical detail drawing of tree protection fencing specifying a 1.20m height above ground, 600mm depth below ground, and a 2.4m maximum span between posts. The diagram labels include a 38 x 89mm top rail, 38 x 89mm bottom rail, 38 x 89mm posts, and ties or staples to secure the mesh.

CONSTRUCTION SPECIFICATIONS

  • FENCE WILL BE CONTRUCTED USING 38 X 89 mm (2"X4") WOOD FRAME: TOP, BOTTOM AND POSTS. *
  • USE ORANGE SNOW-FENCING MESH AND SECURE TO THE WOOD FRAME WITH "ZIP" TIES OR GALVANZIED STAPLES
    • IN ROCKY AREAS, METAL POSTS (T-BAR OR REBAR) DRILLED INTO ROCK WILL BE ACCEPTED

PROJECT DETAILS

Field Value
DETAIL NAME: TREE PROTECTION FENCING
DATE: Oct 30/07
DRAWN: DM
APP'D: RR
SCALE: N.T.S.
DRAWING: E105
Page 55
