Council Meeting/Documents/Preliminary Lot Dimension Plan - Lifestyle Ventures Inc.
Appendix

Preliminary Lot Dimension Plan - Lifestyle Ventures Inc.

April 7, 2015Page 761 section

Detailed engineering plan for the 54-lot subdivision at the Langford/View Royal border.

1 CALL TO ORDER
February 19, 2015Associated Engineering54 single-family lots

Lot Dimension Plan - PCC Property Development

Detailed lot layout plan for the PCC Property Development, showing numbered lots 1-54, dimensions, areas in square meters, a road network including Rainforest Road, and designated protected and stormwater features.
Detailed lot layout plan for the PCC Property Development, showing numbered lots 1-54, dimensions, areas in square meters, a road network including Rainforest Road, and designated protected and stormwater features.

Project Information

  • Client: Lifestyle Ventures Inc.
  • Project: PCC Property Development
  • Drawing Title: Lot Dimension Plan
  • Drawing Number: 2764-2764-00-C-102
  • Scale: 1:500
  • Revision: D
  • Sheet: 02 / 03

Revision History

REV DATE DESIGN DRAWN DESCRIPTION
D 2015-03-15 JB AVS REVISED LOT 49
C 2014-06-27 JB AVS ISSUED FOR SUBMISSION
B 2014-06-11 JB AVS ISSUED FOR SUBDIVISION APPLICATION
A 2014-03-19 JB GA ISSUED FOR SUBDIVISION APPLICATION

Site Notes and Key Features

  • Road Network: Includes "Rainforest Road" and a secondary "Road" servicing the lower lot tier.
  • Protected Areas: A large "PROTECTED AREA" is designated on the western portion of the site, adjacent to Lots 53, 54, and ROW 241.
  • Stormwater Management: A "POSSIBLE STORMWATER STORAGE/WATER FEATURE" is identified near the cul-de-sac by Lots 49 and 50.
  • Covenants: A "15m NO DISTURB COVENANT OVER LOTS 24, 25, 26" is noted on the eastern edge.
  • Site Grading: "EXISTING LOW AREA REQUIRING FILL" is marked along the northern boundary of Lots 1 through 7.
  • Continuity Notes:
    • "FOR CONTINUATION SEE BELOW/LEFT"
    • "FOR CONTINUATION SEE ABOVE/RIGHT"

Lot Schedule (Extracted Areas)

Lot Number Area (m²) Lot Number Area (m²)
Lot 1 506.3 Lot 29 502.2
Lot 2 524.4 Lot 30 502.4
Lot 3 524.4 Lot 31 506.1
Lot 4 537.1 Lot 32 504.6
Lot 5 524.1 Lot 33 504.8
Lot 6 524.1 Lot 34 506.5
Lot 7 532.1 Lot 35 501.6
Lot 8 744.3 Lot 36 501.4
Lot 9 500.4 Lot 37 501.5
Lot 10 502.1 Lot 38 501.2
Lot 11 500.5 Lot 39 500.4
Lot 12 502.2 Lot 40 500.7
Lot 13 500.7 Lot 41 500.8
Lot 14 502.1 Lot 42 806.3
Lot 15 500.5 Lot 43 725.6
Lot 16 501.4 Lot 44 538.8
Lot 17 502.4 Lot 45 654.4
Lot 18 502.4 Lot 46 620.2
Lot 19 502.4 Lot 47 503.4
Lot 20 502.2 Lot 48 502.4
Lot 21 500.4 Lot 49 502.4
Lot 22 532.5 Lot 50 502.4
Lot 23 554.2 Lot 51 501.4
Lot 24 1147.4 Lot 52 523.5
Lot 25 661.1 Lot 53 501.6
Lot 26 521.8 Lot 54 650.7
Lot 27 521.7 ROW 241 534.3
Lot 28 502.4
Page 76
Extracted from: 2015 04 07 Council Agenda
