B.C. Land Surveyor's Site Plan of Lot 7, Plan 168B

B.C. Land Surveyor's Site Plan of Lot 7, Plan 168B16 Block 12, Section 8, Esquimalt District.

Scale 1:250

All distances are in metres. Lot dimensions derived from registered plans and not verified by this survey.

Elevations are derived from View Royal Monument 06-11

CIVIC ADDRESS: 291 Kerwood Road, Victoria, BC P.I.D. 007-104-154

Detailed site plan of Lot 7 showing the property boundaries, dwelling, garage, driveway, decks, and various elevations. The plan includes features such as Kerwood Road, an asphalt area, a water meter, an iron survey post, and a "present natural boundary" at the southern end of the lot.

This plan is prepared from unchecked field data. Check measurements prior to construction.

This document is for approval/discussion purposes only and not to be used for the reestablishment of property boundaries.

This plan was prepared for design purposes and is for the exclusive use of our client.

The signatory accepts no responsibility for any damages that may be suffered by a third party as a result of reproduction, transmission, or alteration to this document without consent of the signatory.

Field Survey: October 2, 2012 Drafted: October 4, 2012

MICHAEL CLAXTON LAND SURVEYING INC. B.C. & Canada Lands Surveyor Unit 80A 4223 Commerce Circle Victoria, B.C. V8Z 6N6 Phone: 250-479-2258 Fax: 250-479-3831 Email: surveys@hilbre.ca File: 18929(site A)
