Appendix

Boathouse location according to survey

April 21, 2015Page 211 section

A zoomed-in survey plan specifically showing the boathouse's relationship to the property boundary and shoreline.

Scale 1:110Approximate boundary as shown on plan 168B

Kerwood 291

Boathouse location according to survey

Scale: 1:10

Survey plan for Kerwood 291 detailing a boathouse building, decks, stairs, and block walls with extensive numerical dimensions and boundary notations.
Survey plan for Kerwood 291 detailing a boathouse building, decks, stairs, and block walls with extensive numerical dimensions and boundary notations.

Survey Notes

  • Dashed lines indicate surveyed location
  • approximate boundary as shown on plan 1688
  • P17

Building and Structures

  • Building Dimensions: 3.76, 2.54, 2.30, 2.54, 3.64, 5.74, 3.64
  • Deck (attached to building): Includes a dimension of 1.2192 and a 61° angle.
  • Main Deck: Dimensions 8.09, 4.66, 0.02, 4.7...
  • Stairs: Dimension 8.24
  • Block Walls: Measurements of 4.77, 4.88, 3.22, 3.08, 3.02, 2.98, 3.00, 1.70, and 2.98
  • Other features: wall, ning wall (retaining wall), prese (present shoreline)

Additional Survey Points and Offsets

  • 1.10
  • 2.33
  • 2.98
  • 2.23
  • 2.39
Page 21
