Appendix

Marked-Up Site Plan for Planting Locations - 77 Caton Place

February 17, 2015Page 521 section

Site plan with hand-drawn annotations indicating intended locations for native restoration plantings.

8.1.a Environmental Development Permit with Variances No. 2014/08 - 77 Caton Place
Legend includes Salal (S), Salmonberry (SB), and Garry Oak (G)

SITE PLAN OF LOT 12, SECTION 29, ESQUIMALT DISTRICT, PLAN 13751

Project Details

  • Scale: 1:150
  • Units: All distances are in metres
  • Field survey dated: February 12th, 2014
  • PID: 004-634-012

Note This site plan is prepared for permitting and design only. CGVD28 geodetic elevations were derived from observations to geodetic control monument VR06-05 (Elevation=5.01). Building dimensions and offsets shown are to the exterior siding.

Legend

  • Denotes water meter
  • Denotes ground elevation
  • Denotes tree location, diameter and species
A detailed site plan of Lot 12, Section 29, Plan 13751, showing a property of ±845 Sq.m. The plan includes the main residence (Civic: #77) and a wood shed. The property is bounded by Caton Place to the north and Craigflower Creek to the south, with Lot 11 and Lot 13 on either side. The map details building setbacks, various ground elevations, tree locations, a driveway, a stone wall, and a north-pointing compass rose.
A detailed site plan of Lot 12, Section 29, Plan 13751, showing a property of ±845 Sq.m. The plan includes the main residence (Civic: #77) and a wood shed. The property is bounded by Caton Place to the north and Craigflower Creek to the south, with Lot 11 and Lot 13 on either side. The map details building setbacks, various ground elevations, tree locations, a driveway, a stone wall, and a north-pointing compass rose.

Surveyor Information

  • Date: February 13, 2014
  • Archive: 37-ROBERTSON-SP
  • Company: Island Land Surveying Ltd.
  • Address: 1-15 Cadillac Avenue, Victoria, B.C. V8Z 1T3
  • Telephone: 250.475.1515
  • Fax: 250.475.1516
  • Website: www.islandsurveying.ca
