Jedburgh Preliminary Layout & Fire Access

July 21, 2015Page 791 section

Engineering sketch detailing the proposed road layout and fire/emergency vehicle access points.

1 CALL TO ORDER
Westbrook Consulting Ltd.July 2015

JEDBURGH JOHN KOREN

PRELIMINARY LAYOUT

Site plan titled "PRELIMINARY LAYOUT" for the Jedburgh project, showing the subdivision of seven lots (SL 1 through SL 7), a proposed road and cul-de-sac, tree retention areas, and a typical road cross-section.
Site plan titled "PRELIMINARY LAYOUT" for the Jedburgh project, showing the subdivision of seven lots (SL 1 through SL 7), a proposed road and cul-de-sac, tree retention areas, and a typical road cross-section.

Project Information
Project JEDBURGH JOHN KOREN
Consulting Firm WESTBROOK Consulting Ltd.
Address #115 - 866 Goldstream Ave., Victoria, BC V9B 0J3
Telephone 250-391-8592
Facsimile 250-391-8593
Date JULY 2015
Project Ref. P-0989
Scale 1:500
Sheet No. FIGURE 1
Drawn WR

Legend

  • PROPOSED ASPHALT: (Indicated by grey shaded areas)
  • PROPOSED CONCRETE DRIVEWAY: (Indicated by stippled grey areas)
  • TREES TO BE RETAINED: (Indicated by green tree symbols)
  • TREES TO BE RETAINED IF FEASIBLE: (Indicated by orange tree symbols)

Typical Cross Section (N.T.S.)

The typical road cross section includes the following specifications:

  • Travel Lanes: Two 3.0m travel lanes with a 2.0% cross-slope.
  • Property Line (PL) Margins: 1.0m clearance from the property line to the edge of the travel area.
  • Curbing: Mountable curb.
  • Pavement Structure:
    • 50mm of Asphalt Paving
    • 50mm of 20mm minus crushed gravel
    • 200mm of 80mm minus crushed gravel placed on a subgrade approved by a geotechnical engineer.

Plan Notes and Annotations

  • Access Note (Handwritten): GATED ACCESS TO TRAIL NO ACCESS TO TRAIL
  • Parking Note (Handwritten): 4 PARKING SPACES MORE REALISTIC (Located near the cul-de-sac and proposed driveways for SL 4 and SL 5)
  • Proposed Infrastructure:
    • Proposed Road (6.0m width)
    • Proposed Fence (Indicated along multiple lot boundaries)
    • Proposed concrete driveways (5.5m and 2.6m widths noted)
    • Turning radius at cul-de-sac: R9.0, R6.0

Lot and Property Details

  • SL 1: 600 Sq.m
  • SL 2: 600 Sq.m
  • SL 3: 600 Sq.m
  • SL 4: 1090 Sq.m
  • SL 5: 629 Sq.m
  • SL 6: 629 Sq.m
  • SL 7: 629 Sq.m (Plan VIS5234)

Surrounding Property References:

  • Lot 6 Plan 45153
  • Lot 3
  • Lot 2 Plan 44877
  • Lot 4 Access
  • REM LOT A PLAN 19042
  • LOT B PLAN VIP71776
  • LOT 1 PLAN 43429
  • LOT 1 PLAN 46640
  • Lot A Plan VIP88427
  • Lot B Plan VIP88427
  • Bishan Place
  • Jedburg Road
  • Jedburg Place
