Topographic Site Plan with Tree Locations - 17 Jedburgh Road

July 21, 2015Page 981 section

Survey map showing exact locations of trees relative to property lines and proposed development.

1 CALL TO ORDER
Oct 2014

Topographic Site Plan

Topographic Site Plan Of: Lot A, Section 8, Esquimalt District, Plan VIP71776.

Scale = 1:500

This document is prepared for municipal purposes only.

Dated this 28th day of October, 2014.

Distances and elevations shown are in metres. Elevations are based upon geodetic datum derived from View Royal Control Monuments.

Topographic site plan of Lot A, Section 8, Esquimalt District, showing the division into seven strata lots (SL 1 through SL 7) and common property. The plan includes topographic contours, spot elevations, and indicates features like an existing house, carport, and pump station. Adjacent properties and landmarks shown include the E & N Railway (Plan VIP66676), Bishon Place, Jedburgh Road, and several surrounding lots.
Topographic site plan of Lot A, Section 8, Esquimalt District, showing the division into seven strata lots (SL 1 through SL 7) and common property. The plan includes topographic contours, spot elevations, and indicates features like an existing house, carport, and pump station. Adjacent properties and landmarks shown include the E & N Railway (Plan VIP66676), Bishon Place, Jedburgh Road, and several surrounding lots.

Strata Lot Areas

Strata Lot Area
SL 1 520 Sq.m
SL 2 522 Sq.m
SL 3 579 Sq.m
SL 4 629 Sq.m
SL 5 608 Sq.m
SL 6 828 Sq.m
SL 7 582 Sq.m

Adjacent and Internal Property References

  • Lot 6 Plan 45153
  • Bishon Place
  • E & N Railway Plan VIP66676
  • Lot 3 Plan 44877
  • Lot 2 Plan 44877
  • Lot 1 Plan 44877
  • Jedburgh Road
  • Common Property
  • Lot 1 Plan 46640
  • Rem. Lot A Plan 19042
  • Lot B Plan VIP71776
  • Lot 1 Plan 43429
  • Lot A Plan VIP88427
  • Lot B Plan VIP88427
  • SL 7 Plan VIS5234

Notes

This subject property is affected by the following registered documents: 20421G, 44733G, 143309G.

Wey Mayenburg Land Surveying Inc. www.weysurveys.com #1-2227 James White Boulevard Sidney, BC V8L 1Z5 Telephone (250) 656-5155 Fax: 1-800-842-1251
