Tree Protection Fencing Detail E105

July 21, 2015Page 991 section

Technical specification for the construction of tree protection fencing.

1 CALL TO ORDER

Oct 30/071.2m high fencing required.

TREE PROTECTION FENCING

Technical diagram of tree protection fencing showing dimensions, materials, and construction details.

Construction Details

Maximum Span: 2.4M
Top Rail: 38 x 89mm
Bottom Rail: 38 x 89mm
Post: 38 x 89mm
Height (Above Ground): 1.20
Depth (Below Ground): 600
Fasteners: Ties or staples to secure mesh

Notes

TREE PROTECTION FENCING FENCE WILL BE CONTRUCTED USING 38 X 89 mm (2"X4") WOOD FRAME: TOP, BOTTOM AND POSTS. *
USE ORANGE SNOW-FENCING MESH AND SECURE TO THE WOOD FRAME WITH "ZIP" TIES OR GALVANZIED STAPLES
- IN ROCKY AREAS, METAL POSTS (T-BAR OR REBAR) DRILLED INTO ROCK WILL BE ACCEPTED

Detail Information

Field	Value
DETAIL NAME:	TREE PROTECTION FENCING
DATE:	Oct 30/07
DRAWN:	DM
APP'D:	RR
SCALE:	N.T.S.
DRAWING:	E105

Page 99

Extracted from: 2015 07 21 Council Agenda
