Boathouse Plan and Elevations - 333 Stewart Avenue

July 21, 2015Page 1091 section

Architectural drawings of the boathouse building elevations.

1 CALL TO ORDER
June 16, 2015T-Square Design & Consulting

Boathouse Plan - 333 Stewart Avenue

Architectural drawing sheet featuring the floor plan and elevations for a boathouse.
Architectural drawing sheet featuring the floor plan and elevations for a boathouse.

Project Identification

  • Owner: Mr. Troy Saladana
  • Project Address: 333 Stewart Avenue
  • Consultant: T-Square Design & Consulting
  • Consultant Address: 2850 Lakehurst Drive, Victoria, BC
  • Consultant Contact: 250-382-2893 | design@tsquare.ca
  • Date: June/15
  • Drawing No: 053-H
  • Scale: As Shown
  • Designed By: Others
  • Drawn By: J.L.

Drawings and Specifications

Boathouse Plan

  • Scale: 1/4" = 1'-0"
  • Floor Area: 290 sq. ft. (27.0 m²)
  • Details: Adjacent to "WATER", includes "DECK" area and "6"x6" posts".

Front (West) Elevation

  • Scale: 1/4" = 1'-0"

Side (South) Elevation

  • Scale: 1/4" = 1'-0"

Side (North) Elevation

  • Scale: 1/4" = 1'-0"
  • Material Notes: Cedar shingle, 1x4 trim

Rear (East) Elevation

  • Scale: 1/4" = 1'-0"
