Site Plan - Outdoor Playground (100 Aldersmith Place)

July 21, 2015Page 1261 section

Design plan for the daycare playground showing fencing, mulch, and buffer zones.

1 CALL TO ORDER
June 29, 2015J.E. Anderson and Associates

SITE PLAN AT 100 ALDERSMITH PLACE

Site plan map for Strata Lot A at 100 Aldersmith Place, showing property boundaries, a designated fence area highlighted in red, concrete sidewalks, a kiosk, and adjacent strata plan VIS 4586. The map includes area measurements of 1,819 sq. ft. (150.5 sq. m.) and 5,581 sq. ft. (513.5 sq. m.), along with topographical labels such as "Back of Curb" and "Toe of Boulder Wall".
Site plan map for Strata Lot A at 100 Aldersmith Place, showing property boundaries, a designated fence area highlighted in red, concrete sidewalks, a kiosk, and adjacent strata plan VIS 4586. The map includes area measurements of 1,819 sq. ft. (150.5 sq. m.) and 5,581 sq. ft. (513.5 sq. m.), along with topographical labels such as "Back of Curb" and "Toe of Boulder Wall".

Legend

  • Red Line: Fence

Specifications:

  • Total Outside Area: 7,200 sq. ft. (669 sq. m.)
  • Fence: 4' high black chainlink fence
  • Ground Cover: 6" of bark mulch

Notes:

ELEVATIONS ARE TO ASSUMED DATUM. THE DECIMAL POINT OF THE ELEVATION DENOTES THE LOCATION OF THE SHOT TAKEN UNLESS OTHERWISE NOTED. PROPERTY LINES HAVE BEEN CALCULATED FROM CURRENT SURVEY AND EXISTING SURVEY RECORDS.

Project Information

J.E. Anderson and Associates SURVEYORS ENGINEERS VICTORIA | NANAIMO

Field Detail
SITE PLAN AT 100 ALDERSMITH PLACE
LEGAL STRATA LOT A, SECTION 2, ESQUIMALT DISTRICT, STRATA PLAN VIS4586
CLIENT TPM MANAGEMENT LTD. REVESCO PROPERTIES
DRAWN BY DDL
PROJECT SURVEYOR COLIN GROVER
SCALE 1:250
DATE JUNE 29, 2015
OUR FILE 29116
REVISION
Page 126
Extracted from: 2015 07 21 Council Agenda
