Thetis Vale Phase 6 Typical Cross Sections

THETIS VALE PHASE 6

TYPICAL CROSS SECTIONS

Project No.: 20132450 Scale: 1:500 Drawn: DAH Designed: DAH Client: LIMONA CONSTRUCTION Drawing Number: 2450-00-XS101 Rev. No.: G Sheet: 13

Engineering drawing sheet showing site layout and cross-sections for Thetis Vale Phase 6 development.

Volume Calculations

CUT: 28,800 m³
FILL: 33,500 m³
(EXCLUDES STRIPPING AND BULKING)

Revisions

NO.	DATE	ENG	BY	SUBJECT
G	MAY 6, 2015	DG	DAH	ISSUED FOR CONSTRUCTION
F	APR. 29, 2015	DG	DAH	ISSUED FOR FINAL APPROVAL
E	MAR. 23, 2015	DG	DAH	REVISED FOR FINAL APPROVAL
D	JAN. 12, 2015	DG	DAH	RE-ISSUED FOR APPROVAL
C	AUG. 1, 2014	DG	DAH	RE-ISSUED FOR APPROVAL

Drawing Details

The drawing includes several cross-sections and a site plan:

X-SECTION 1-1: Shows vertical profile across a portion of the site from 0+000 to 0+070.
X-SECTION 2-2: Shows vertical profile across townhouses from 1+000 to 1+160.
X-SECTION 3-3: Shows vertical profile from 2+000 to 2+120.
X-SECTION 4-4: Detail of mortared rock wall (chilco frontage).
X-SECTION 5-5: Detail of mortared rock wall.

Site Plan Features

The site plan details the following lots and areas:

Roads: CHEAM ROAD, TOWNHOUSE RD.
Lots:
- Lot 7 (425 sq.m.)
- Lot 8 (505 sq.m.)
- Lot 9 (463 sq.m.)
- Lot 10 (403 sq.m.)
- Lot 11 (750 sq.m.)
- Lot 12 (438 sq.m.)
- Lot 13 (372 sq.m.)
- Lot 14 (388 sq.m.)
- Lot 15 (342 sq.m.)
- Lot 16 (385 sq.m.)
- Lot 17 (385 sq.m.)
- Lot 18 (317 sq.m.)
- Lot 19 (614 sq.m.)
- Lot 20 (2073 sq.m.)
Green Spaces:
- GREEN SPACE 0.13 ha.
- GREEN SPACE 0.11 ha.
- GREEN SPACE 0.07 ha.
- GREEN SPACE 0.07 ha.
- GREEN SPACE 0.06 ha.
