Certificate of Location Survey - 263 View Royal Avenue

July 21, 2015Page 1732 sections

Land survey showing existing structures and the proposed deck area relative to property boundaries.

1 CALL TO ORDER
Oct 19, 2012Island Land Surveying Ltd.

B.C. LAND SURVEYORS CERTIFICATE OF LOCATION OF DWELLING ON

LOT 6, BLOCK 13, SECTION 27, ESQUIMALT DISTRICT, PLAN 1688.

PID: 007-104-235

Field survey dated this 19th day of October, 2012. SCALE=1:500. All distances are in metres.

NOTE:

Dimensions shown are based upon field survey measurements and may vary from those registered. A comprehensive legal survey may reveal offsets to boundaries that differ from those shown. The parcel is subject to charges:

  • Right of Way 260561G
  • Restrictive Covenant 92803G

Elevations shown ( . ) are based upon geodetic datum.

Survey map showing Lot 6 and adjacent properties (Lot 5, Lot A, REM. LOT 1) with building footprints for a house (Main Floor Elev.=27.88m) and a cottage (Main Floor Elev.=10.56m). The map details proximity to View Royal Avenue and Esquimalt Harbour, including features like a carport, deck, seawall, and present natural boundary.
Survey map showing Lot 6 and adjacent properties (Lot 5, Lot A, REM. LOT 1) with building footprints for a house (Main Floor Elev.=27.88m) and a cottage (Main Floor Elev.=10.56m). The map details proximity to View Royal Avenue and Esquimalt Harbour, including features like a carport, deck, seawall, and present natural boundary.

I have examined the residential premises shown and hereby certify that the said structure is situate with respect to nearby boundaries as shown. This document is prepared for building inspection or mortgage purposes only and is for the exclusive use of our client. This document is not valid unless originally signed and sealed. This document shall not be used to define property lines or property corners. Unregistered interests have not been included or considered.

Page 173

LOT INFORMATION:

Category Value
CIVIC ADDRESS 263 VIEW ROYAL AVENUE
PROPOSED ZONING R-1
TOTAL LOT AREA 1974.51 sq.m.+/-
ALLOWABLE LOT COVERAGE 35% 691.07 sq.m.
EXISTING/PROPOSED LOT COVERAGE
HOUSE 199.00 sq.m.
CABIN 73.08 sq.m.
TOTAL 272.08 sq.m.
PERCENTAGE 13.77%
