Site Plan - Lot B, Section 8, Esquimalt District

Site Plan Of: Lot B, Section 8, Esquimalt District, Plan VIP81834.

Dated this 27th day of February, 2015.

Distances and elevations shown are in metres. Elevations are based upon geodetic datum and referenced to OCM VR08-10. To obtain elevations based on chart datum add 1.9m. Scale = 1" = 10.0'

Site plan diagram for 333a Stewart Avenue, showing property lines for Lot A and Lot B, topographical contour lines, existing structures, vegetation, and a proposed dock installation in Helmcken Bay.

Proposed Dock - 333a Stewart Avenue

Site Features and Infrastructure:

Waterfront: Helmcken Bay
Top of Neighbours Wharf: = 2.4m
Existing Improvements:
- Existing Concrete Patio
- Existing Concrete Walkway
- Re-build Existing Steps
- Existing Patio
- Wall
- Rip-Rap and Top of Rip-Rap
- Outbuilding (Main Floor = 10.92)
- House (locations indicated on adjacent lots)
Proposed Improvements:
- New Wood Walkway
- Proposed Ramp (measurements: 11.19, 14.39)
- Proposed Dock (9.14m)
- Deck (3.66m)
Environmental Features:
- Natural Boundary Per Plan EPP10028
- Significant Lichens
- Approximate Chart Datum
Vegetation Survey:
- 0.90 Deciduous
- 0.55 Deciduous
- Twin Deciduous
- 0.30 Deciduous
- 0.80 Deciduous
- 0.25 Coniferous

Property Boundaries and Survey Data:

Adjoining Property: Lot 17, Block 6, Plan 1688
Boundary Measurements: 25.50, 13.67, 9.21, 61.2+/-, 22.8+/-
Setback/Access Measurements: 1.6m, 1.4m

Professional Services

Wey Mayenburg Land Surveying Inc www.weysurveys.com #4-2227 James White Boulevard Sidney, BC V8L 1Z5 Telephone (250) 656-5155 File: 1101241SITE

Bruce Wilkin Design Sheet Three of Four Date - May 4, 2015 designers + builders
