Appendix: Concept Plan 2A - EFN Access Options

June 23, 2015Page 811 section

Engineering drawing showing the proposed detail plan for Hallowell Road and the trail connection.

1 CALL TO ORDER
Drawing 2935-00-C-210Associated EngineeringMay 13, 2015

Hallowell Road EFN Access Options - Civil Concept Plan 2A

Engineering drawing showing a detail plan and context plan for Hallowell Road EFN Access Options, featuring road lane widths, parking areas, and a trail layout.
Engineering drawing showing a detail plan and context plan for Hallowell Road EFN Access Options, featuring road lane widths, parking areas, and a trail layout.

Plan Overview

  • 1 Detail Plan: Scale 1:200. Features include a 4.0 m lane, 2.4 m parking, 3.5 m lane, and 3.25 m trail along Hallowell Rd.
  • 2 Context Plan: Scale 1:750. Shows the broader project area including a 10.0 m ROW.

Project Information

  • Client: Capital Regional District
  • Project: Hallowell Road EFN Access Options
  • Project Number: 2015-2935-00
  • Drawing Title: Civil Concept Plan 2A
  • Drawing Number: 2935-00-C-210
  • Scale: As Noted
  • Status: Preliminary / For Discussion / Not For Construction / Draft

Revision History

REV DATE DESIGN DRAWN DESCRIPTION
A 2018-01-09 KD DA ISSUED FOR INFORMATION
B 2018-05-13 KD DA ISSUED FOR INFORMATION
C 2018-05-15 KD DA ISSUED FOR INFORMATION
Page 81
