Appendix: Concept Plan 2A - Truck Movements

June 23, 2015Page 821 section

Engineering drawing simulating fire truck and HSU movements on the proposed Hallowell Road alignment.

1 CALL TO ORDER
Drawing 2935-00-C-211Associated Engineering

CAPITAL REGIONAL DISTRICT

HALLOWELL ROAD EFN ACCESS OPTIONS

CIVIL CONCEPT PLAN 2A TRUCK MOVEMENTS

Technical drawing showing truck turning path simulations at Hallowell Road. The drawing includes two plan views: one for Fire Truck Movement and one for HSU Movement, along with vehicle specifications.
Technical drawing showing truck turning path simulations at Hallowell Road. The drawing includes two plan views: one for Fire Truck Movement and one for HSU Movement, along with vehicle specifications.

Plan 3: FIRE TRUCK MOVEMENT

Scale: 1:200

Vehicle Specifications: Fire Engine 58

Dimension Measurement
Width 2.45 meters
Track 2.32 meters
Lock to Lock Time 6.0 seconds
Steering Angle 41.3 degrees
Overall Length 9.60 meters

Plan 3: HSU MOVEMENT

Scale: 1:200

Vehicle Specifications: HSU

Dimension Measurement
Width 2.50 meters
Track 2.50 meters
Lock to Lock Time 6.0 seconds
Steering Angle 33.7 degrees
Overall Length 11.50 meters

Project Information

  • Project No.: 2015-2935-00
  • Drawing No.: 2935-00-C-211
  • Scale: AS NOTED
  • Revision: A

Revision History

Rev Date Description
A 2015/04/21 ISSUED FOR INFORMATION
